REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
CPD-E220/E215E/E220E
7-2
(a)
D203 8-719-970-82 DIODE HSS82 4130190820
D204 8-719-970-82 DIODE HSS82 4130190820
D205 8-719-970-82 DIODE HSS82 4130190820
D301 8-719-911-19 DIODE 1SS119-25 4120511900
D302 8-719-911-19 DIODE 1SS119-25 4120511900
D303 8-719-970-82 DIODE HSS82 4130190820
D304 8-719-970-82 DIODE HSS82 4130190820
D305 8-719-970-82 DIODE HSS82 4130190820
<FERRITE BEAD>
FB001 BEAD, FERRITE 0.45µH 7099458250
FB002 1-469-611-11 INDUCTOR, FERRITE BEAD 2µH 4322209005
FB003 JUMP WIRE 5406100000
FB004 JUMP WIRE 5406100000
FB005 JUMP WIRE 5406100000
FB006 1-469-402-11 BEAD, FERRITE 3µH 4322309006
FB101 JUMP WIRE 5406100000
FB201 JUMP WIRE 5406100000
FB301 JUMP WIRE 5406100000
<IC>
IC001 8-759-582-06 IC M52743BSP 4159527432
IC002 8-759-569-64 IC BH3863F
IC003 IC M35047-XXX 4159350470
IC004 8-759-991-16 IC LM358N 4159358000
<SOCKET, PICTURE TUBE>
J001 0 1-251-598-11 SOCKET, PICTURE TUBE 4570307Y11
<COIL>
L001 1-469-400-11 INDUCTOR, MICRO 100µH 432B101006
L002 JUMP WIRE 5406100000
L101 1-469-398-11 INDUCTOR, MICRO 0.1µH 432B108006
L102 INDUCTOR, MICRO 0.47µH 432B478006
L201 1-469-398-11 INDUCTOR, MICRO 0.1µH 432B108006
L202 INDUCTOR, MICRO 0.47µH 432B478006
L301 1-469-398-11 INDUCTOR, MICRO 0.1µH 432B108006
L302 INDUCTOR, MICRO 0.47µH 432B478006
<TRANSISTOR>
Q001 8-729-139-04 TRANSISTOR 2N3904 4111139040
Q002 8-729-139-04 TRANSISTOR 2N3904 4111139040
Q003 8-729-139-04 TRANSISTOR 2N3904 4111139040
Q004 8-729-823-81 TRANSISTOR 2SC4632LS-CB7 4100246340
Q005 8-729-206-21 TRANSISTOR RN1203 4116612030
Q008 8-729-139-04 TRANSISTOR 2N3904 4111139040
Q101 TRANSISTOR BF420 4114804200
Q201 TRANSISTOR BF420 4114804200
Q301 TRANSISTOR BF420 4114804200
<RESISTOR>
R001 1-247-807-91
CARBON (SMALL) 100 1/4W 4050510155
R002 1-247-807-91
CARBON (SMALL) 100 1/4W 4050510155
R004 1-216-025-91 RES-CHIP 100
1/10W 4010110152
R005 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
R006 1-216-073-91 RES-CHIP 10K 1/10W 4010110352
R007 RES-CHIP 100
1/10W 4010110152
R008 RES, CHIP 2.4K
1/10W 4010124252
R009 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
R010 1-216-025-91 RES-CHIP 100
1/10W 4010110152
R011 RES-CHIP 470 1/10W 4010147152
R012 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
R013 1-216-065-11 RES-CHIP 4.7K
1/10W 4010147252
R014 1-216-065-11 RES-CHIP 4.7K
1/10W 4010147252
R015 1-247-816-91
CARBON (SMALL) 240 1/4W 4050524155
R016 RES-CHIP 470 1/10W 4010147152
R017 1-247-807-91
CARBON (SMALL) 100 1/4W 4050510155
R018 1-216-025-91 RES-CHIP 100
1/10W 4010110152
R019 1-216-025-91 RES-CHIP 100
1/10W 4010110152
R020 METAL FILM 4.42K 1/4W 4257044421
R021 RES-CHIP 32.4K
1/10W 419A132422
R022 RES, CHIP 2.4K
1/10W 4010124252
R023 RES-CHIP 1M
1/10W 4010110552
R024
CARBON (SMALL) 150K 1/4W 4050515455
R025
CARBON (SMALL) 2.2K 1/4W 4050522255
R026 RES-CHIP 470
1/10W 4010147152
R027 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
R028 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
R029 1-216-053-11 RES-CHIP 1.5K
1/10W 4010115252
R030 1-216-073-91 RES-CHIP 10K
1/10W 4010110352
R031 METAL FILM 22M 1/4W 4160422655
R032 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
R033 RES-CHIP 220K
1/10W 4010122452
R034 10K 1/2W 4050210355
R035 METAL FILM 2.2M 1/2W 4160222555
R036 RES-CHIP 100 1/10W 4010110152
R037 RES-CHIP 100
1/10W 4010110152
R039 RES, CHIP 2.4K
1/10W 4010124252
R042 100 1/2W 4050210155
R046 RES-CHIP 3K
1/10W 4010130252
R049 1-216-073-91 RES-CHIP 10K
1/10W 4010110352
R050 1-216-065-11 RES-CHIP 4.7K
1/10W 4010147252
R051 1-216-053-11 RES-CHIP 1.5K
1/10W 4010115252
R054 RES-CHIP 1M
1/10W 4010110552
R101 1-216-022-11 RES-CHIP 75
1/10W 4010175002
R103 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
R104
CARBON (SMALL) 12 1/4W 4050512055
R107 1-247-847-91
CARBON (SMALL) 4.7K 1/4W 4050547255
R108
CARBON (SMALL) 20K 1/4W 4050520355
R109 RES-CHIP 470
1/10W 4010147152
R111 1-247-903-91
CARBON (SMALL) 1M 1/4W 4050510555
R112 300 1/2W 4050230155
R113 1-216-013-11 RES-CHIP 33
1/10W 4010133052
R115 62 1/2W 4050262055
R201 1-216-022-11 RES-CHIP 75
1/10W 4010175002
R203 1-216-049-91 RES-CHIP 1K
1/10W 4010110252
