REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
CPD-E220/E215E/E220E
7-3
(a)(d)
R204
CARBON (SMALL)
12 1/4W 4050512055
R207 1-247-847-91
CARBON (SMALL)
4.7K 1/4W 4050547255
R208
CARBON (SMALL)
20K 1/4W 4050520355
R209 1-247-823-91
CARBON (SMALL)
470 1/4W 4050547155
R211 1-247-903-91
CARBON (SMALL)
1M 1/4W 4050510555
R212 300 1/2W 4050230155
R213 1-216-013-11 RES-CHIP 33
1/10W
4010133052
R215 100 1/2W 4050210155
R301 1-216-022-11 RES-CHIP 75
1/10W
4010175002
R302 JUMP WIRE 5406100000
R303 1-216-049-91 RES-CHIP 1K
1/10W
4010110252
R304
CARBON (SMALL)
12 1/4W 4050512055
R307 1-247-847-91
CARBON (SMALL)
4.7K 1/4W 4050547255
R308
CARBON (SMALL)
20K 1/4W 4050520355
R309 1-247-823-91
CARBON (SMALL)
470 1/4W 4050547155
R311 1-247-903-91
CARBON (SMALL)
1M 1/4W 4050510555
R312 300 1/2W 4050230155
R313 1-216-013-11 RES-CHIP 33
1/10W
4010133052
R315 62 1/2W 4050262055
<SPARK GAP>
SG001 SPARK GAP 7183330556
SG101 SPARK GAP 4700000003
SG201 SPARK GAP 4700000003
SG301 SPARK GAP 4700000003
******************************************************************************************
D BOARD, COMPLETE
***************************
1-500-644-11 INDUCTOR (D521, D623, D627)
1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
(CN503, R530, R603, R614, R653)
1-533-223-11 HOLDER, FUSE (F601) 46905Y1101
1-785-907-11 PLUG, CONNECTOR 1P
(R576, R583, R605, R653) 3340101525
4-382-854-01 SCREW (M3X8), P, SW (+)
(C409, IC605, IC607, Q503, Q506, Q508,
Q517, Q518, Q519, Q534, Q544, Q602)
<CAPACITOR>
C401 1-137-395-91
METALIZED FILM
0.1µF 250V 5074104102
C402 1-128-528-91 ELECT 470µF 25V 5156471S25
C403 1-137-395-91 PETP FILM 0.022µF 100V 5116223111
C404 1-107-491-91 ELECT 1000µF 25V 5153102S25
C405 1-137-378-91 PETP FILM 0.22µF 50V 5110224550
C406 1-137-390-91 PETP FILM 0.0033µF 100V 5116332111
C408 1-126-951-11 ELECT 470µF 35V 5156471S35
C409 1-108-365-51
PE TEREPHTHALATE
0.001µF 100V 5116102111
C502
METALIZED FILM
0.1µF 50V 5077104505
C503
METALIZED FILM
0.1µF 50V 5077104505
C504 1-137-393-91 PETP FILM 0.01µF 100V 5116472511
C505
METALIZED FILM
0.1µF 50V 5077104505
C506 1-137-393-91 PETP FILM 0.01µF 100V 5116103511
C507 1-137-391-91 PETP FILM 0.0047µF 100V 5116472511
C508 1-163-251-11 CERAMIC 100pF 50V 7183101556
C509 0.0033µF 50V 5144332550
C510 1-107-884-91 ELECT 1000µF 16V 5153102S25
C512 1-163-251-11 CERAMIC 100pF 50V 7183101556
C513 1-163-251-11 CERAMIC 100pF 50V 7183101556
C514 1-165-319-11 CERAMIC 0.1µF 50V 7146104456
C515 1-136-195-11
METALIZED FILM
0.022µF 250V 5074223102
C517 1-128-981-11 CERAMIC 220pF 3KV 510H221193
C518 CERAMIC 1500pF 1KV 5101152132
C521 4300pF 2KV 51904323A3
C522 1-117-958-11 FILM 0.24µF 400V 5199244543
C523 1-126-964-91 ELECT 10µF 50V 5156100T50
C524 1-117-660-21 PETP FILM 0.12µF 250V 5198124583
C525 1-117-659-21 PETP FILM 0.1µF 250V 5198104583
C528 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C529 1-136-497-11
METALIZED FILM
0.1µF 50V 5134104452
C531 1-137-393-91 PETP FILM 0.01µF 100V 5116103511
C532
METALIZED FILM
0.047µF 100V 5074473101
C533 1-126-961-91 ELECT 2.2µF 50V 5156229T50
C534 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C535 1-126-933-11 ELECT 100µF 16V 5156101T16
C536 1500pF 1.6KV 5192152573
C537 CERAMIC 3900pF 1KV 5101392132
C539 1-128-563-11 ELECT 68µF 100V 5156680T01
C540 1-165-319-11 CERAMIC 0.1µF 50V 7146104456
C541 1-135-395-11 ELECT 4.7µF 50V 5156479T50
C542 1-137-395-91 PETP FILM 0.022µF 100V 5116223111
C543 CERAMIC 1000pF 100V 5101102112
C545 1-126-964-91 ELECT 10µF 50V 5156100T50
C546 CERAMIC 100pF 50V 5101101152
C547
METALIZED FILM
0.1µF 50V 5077104505
C548 ELECT 330µF 25V 5156331T25
C549 ELECT 330µF 25V 5156331T25
C550 1-135-352-11
METALIZED FILM
0.01µF 250V 5074103102
C553 470pF 50V 7183471556
C554 CERAMIC 470pF 50V 5128471552
C555 1-136-497-11
METALIZED FILM
0.1µF 50V 5134104452
C556 1-165-319-11 ELECT 100µF 250V 515X101S03
C558 1-137-419-11 PETP FILM 0.0033µF 100V 5116333111
C559 1-136-684-51 PETP FILM 0.0022µF 100V 5116222111
C560 0.1µF 50V 7146104456
C561 680pF 50V 7144681156
C562 0.1µF 50V 7146104456
C563 ELECT 330µF 16V 5156331T16
C564 ELECT 47µF 25V 5156470T25
C565 ELECT 4.7µF 250V 5156479S03
C566 1µF 250V 5190105583
C567 CERAMIC 0.01µF 2KV 51041034C3
C570 1-126-964-91 ELECT 10µF 50V 5156100T50
C571 0.1µF 50V 7146104456
C572 ELECT 47µF 16V 5156470T16
C573 ELECT 4.7µF 35V 5162479T35
C574 ELECT 330µF 50V 5156331S50
C575 0.01µF 50V 7146103456
C576 0.1µF 50V 7146104456
