REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
CPD-E220/E215E/E220E
7-4
(d)
C577 ELECT 22µF 250V 5156220S03
C580 1-137-378-91 PETP FILM 0.22µF 50V 5110224550
C581 1-137-378-91 PETP FILM 0.22µF 50V 5110224550
C582 ELECT 220µF 100V 5156221T01
C583 ELECT 4.7µF 100V 515X479T01
C584 2200pF 50V 7144222156
C585 CERAMIC 1000pF 500V 5101102142
C589 1-135-398-11 ELECT 1µF 50V 5156109T50
C590 0.1µF 50V 7146104456
C591 0.1µF 50V 7146104456
C592 ELECT 4.7µF 35V 5162479T35
C593 PETP FILM 0.22µF 50V 5113224150
C595
METALIZED FILM
0.1µF 400V 5074104104
C598 0.1µF 50V 7146104456
C599 1-126-969-11 ELECT 220µF 50V 5156221T50
C6010 0.47µF 250V 5067474425
C6020 0.47µF 250V 5067474425
C6030 1-135-380-11 CERAMIC 470pF 250V 5063471325
C6040 1-135-380-11 CERAMIC 470pF 250V 5063471325
C605 1-135-351-11 CERAMIC 4700pF 250V 5063472425
C606 1-135-396-11 ELECT 220µF 450V 515P331S45
C607 ELECT 220µF 35V 5156221T35
C608
METALIZED FILM
0.1µF 400V 5074104104
C609
METALIZED FILM
0.33µF 400V 5074334104
C611 680pF 50V 7144681156
C612 1-137-393-91 PETP FILM 0.01µF 100V 5116103511
C613 270pF 50V 7144271156
C614 0.1µF 50V 7146104456
C616 0.1µF 50V 7146104456
C618 1-126-964-91 ELECT 10µF 50V 5156100T50
C619 0.1µF 50V 7146104456
C620 CERAMIC 100pF 1KV 510H101132
C622 0.22µF 50V 5113224150
C623 100pF 50V 7183101556
C625 1-125-700-11 ELECT 220µF 100V 5156221S01
C626 1-107-955-91 ELECT 100µF 250V 515X101S03
C628 1-107-491-91 ELECT 1000µF 25V 5153102S25
C630 1-128-528-91 ELECT 470µF 25V 5156471S25
C631 0.1µF 50V 7146104456
C632 1-128-528-91 ELECT 470µF 25V 5156471S25
C633 1-107-491-91 ELECT 1000µF 25V 5153102S25
C634 1-107-884-91 ELECT 1000µF 16V 5156102S16
C635 ELECT 1000µF 10V 5156102S10
C638 1-164-143-11 CERAMIC 1000pF 1KV 5101102132
C6400 0.1µF 250V 5067104425
C643 0.1µF 50V 7146104456
C645 1-126-935-91 ELECT 470µF 16V 5156471T16
C646 1-107-491-91 ELECT 1000µF 25V 5153102S25
C647 1-135-401-11 ELECT 100µF 35V 5156101T35
C6480 CERAMIC 4700pF 400V 5061472440
C6490 CERAMIC 4700pF 400V 5061472440
C650
METALIZED FILM
0.22µF 400V 5074223104
C651 1-107-491-91 ELECT 1000µF 25V 5153102S25
C652
METALIZED FILM
0.22µF 250V 5077224102
C654 ELECT 22µF 25V 5156220T25
C655 ELECT 10µF 160V 5156100T02
C902 1-126-961-91 ELECT 2.2µF 50V 5156229T50
C903 1-126-961-91 ELECT 2.2µF 50V 5156229T50
C904 1-126-961-91 ELECT 2.2µF 50V 5156229T50
C905 1-126-961-91 ELECT 2.2µF 50V 5156229T50
C906 1-126-961-91 ELECT 2.2µF 50V 5156229T50
C907 1-126-964-91 ELECT 10µF 50V 5156100T50
C908 0.1µF 50V 7146104456
C909 470pF 50V 7183471556
C910 0.1µF 50V 7146104456
C914 100pF 50V 7183101556
C915 1-102-529-91 CERAMIC 100pF 50V 5128101552
C918 47pF 50V 7183470556
C919 47pF 50V 7183470556
C920 0.1µF 50V 7146104456
C921 22pF 50V 7183220556
C922 22pF 50V 7183220556
C923 1-126-961-91 ELECT 2.2µF 50V 5156229T50
C924 ELECT 4.7µF 50V 5156479T50
C925 0.1µF 50V 7146104456
C926 100pF 50V 7183101556
C927 100pF 50V 7183101556
<CONNECTOR>
CN501 6P
CN502 4P
CN503 1-506-108-41
PIN, CONNECTOR (TERMINAL PIN)
3340236016
CN504 1P
CN505 2P C488020185
CN60101-251-444-11 AC SOCKET 4570707C00
CN602 PIN, CONNECTOR 3P 4490301100
CN603 7P
CN901 9P
CN902 7P 4490700330
CN903* 1-564-507-51 PLUG, CONNECTOR 4P 4490400330
<DIODE>
D402 8-719-200-02 DIODE 10E2 4120104002
D501 8-719-911-19 DIODE 1SS119-25 4120511900
D502 8-719-110-39 ZENER DIODE RD15ES-B1
D503 8-719-052-86 DIODE D2L40-TA 4130152400
D504 8-719-911-19 DIODE 1SS119-25 4120511900
D506 8-719-911-19 DIODE 1SS119-25 4120511900
D507 8-719-987-31 DIODE SB140-6339 4130104140
D508 DIODE 5TUZ47CTO-220NIS 413050Z470
D509 DIODE PS104R 4130101040
D510 8-719-911-19 DIODE 1SS119-25 4120511900
D511 DIODE PS104R 4130101040
D512 DIODE PS104R 4130101040
D513 8-719-074-13 DIODE BYV26C 413010426C
D514 8-719-074-25 DIODE PG104R 4130101041
D515 8-719-074-13 DIODE BYV26C 413010426C
D516 DIODE 1N4148 4129141480
D517 8-719-911-19 DIODE 1SS119-25 4120511900
