REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-G400
7-4
R049 1-216-093-91 RES,CHIP 68K 5% 1/10W
R050 1-216-121-91 RES,CHIP 1M 5% 1/10W
R051 1-216-025-91 RES,CHIP 100 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R054 1-216-073-00 RES,CHIP 10K 5% 1/10W
R055 1-216-025-91 RES,CHIP 100 5% 1/10W
R060 1-414-231-22 INDUCTOR CHIP
R064 1-219-749-91 CARBON 10K 5% 1/2W
R077 1-216-077-91 RES,CHIP 15K 5% 1/10W
R078 1-216-089-91 RES,CHIP 47K 5% 1/10W
R079 1-216-089-91 RES,CHIP 47K 5% 1/10W
R080 1-216-049-91 RES,CHIP 1K 5% 1/10W
R081 1-216-049-91 RES,CHIP 1K 5% 1/10W
R082 1-216-089-91 RES,CHIP 47K 5% 1/10W
R083 1-216-089-91 RES,CHIP 47K 5% 1/10W
R085 1-216-049-91 RES,CHIP 1K 5% 1/10W
R086 1-216-041-00 RES,CHIP 470 5% 1/10W
R087 1-216-097-91 RES,CHIP 100K 5% 1/10W
R088 1-216-089-91 RES,CHIP 47K 5% 1/10W
R090 1-216-049-91 RES,CHIP 1K 5% 1/10W
R092 1-216-077-91 RES,CHIP 15K 5% 1/10W
R093 1-216-041-00 RES,CHIP 470 5% 1/10W
R094 1-216-097-91 RES,CHIP 100K 5% 1/10W
R095 1-216-121-91 RES,CHIP 1M 5% 1/10W
R096 1-216-033-00 RES,CHIP 220 5% 1/10W
R097 1-218-179-11 RES,CHIP 10M 5% 1/10W
R098 1-218-179-11 RES,CHIP 10M 5% 1/10W
R099 1-208-291-11 RES,CHIP 4.7M 5% 1/10W
R101 1-215-395-00 METAL 82 1% 1/4W
R104 1-216-009-91 RES,CHIP 22 5% 1/10W
R106 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R107 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R108 1-216-049-91 RES,CHIP 1K 5% 1/10W
R109 1-216-041-00 RES,CHIP 470 5% 1/10W
R110 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R111 1-249-403-11 CARBON 68 5% 1/4W F
R115 1-216-107-00 RES,CHIP 270K 5% 1/10W
R117 1-216-019-00 RES,CHIP 56 5% 1/10W
R118 1-216-013-00 RES,CHIP 33 5% 1/10W
R119 1-216-113-00 RES,CHIP 470K 5% 1/10W
R120 1-216-113-00 RES,CHIP 470K 5% 1/10W
R122 1-216-113-00 RES,CHIP 470K 5% 1/10W
R123 1-216-037-00 RES,CHIP 330 5% 1/10W
R130 1-216-019-00 RES,CHIP 56 5% 1/10W
R133 1-216-019-00 RES,CHIP 56 5% 1/10W
R140 1-216-019-00 RES,CHIP 56 5% 1/10W
R151 1-219-742-11 CARBON 47 5% 1/2W
R161 1-215-395-00 METAL 82 1% 1/4W
R201 1-215-395-00 METAL 82 1% 1/4W
R204 1-216-009-91 RES,CHIP 22 5% 1/10W
R206 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R207 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R208 1-216-049-91 RES,CHIP 1K 5% 1/10W
R209 1-216-041-00 RES,CHIP 470 5% 1/10W
R210 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R211 1-249-403-11 CARBON 68 5% 1/4W
F
R215 1-216-107-00 RES,CHIP 270K 5% 1/10W
R217 1-216-019-00 RES,CHIP 56 5% 1/10W
R218 1-216-013-00 RES,CHIP 33 5% 1/10W
R219 1-216-113-00 RES,CHIP 470K 5% 1/10W
R220 1-216-113-00 RES,CHIP 470K 5% 1/10W
R222 1-216-113-00 RES,CHIP 470K 5% 1/10W
R223 1-216-037-00 RES,CHIP 330 5% 1/10W
R230 1-216-019-00 RES,CHIP 56 5% 1/10W
R233 1-216-019-00 RES,CHIP 56 5% 1/10W
R240 1-216-019-00 RES,CHIP 56 5% 1/10W
R251 1-219-742-11 CARBON 47 5% 1/2W
R261 1-215-395-00 METAL 82 1% 1/4W
R301 1-215-395-00 METAL 82 1% 1/4W
R304 1-216-009-91 RES,CHIP 22 5% 1/10W
R306 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R307 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R308 1-216-049-91 RES,CHIP 1K 5% 1/10W
R309 1-216-041-00 RES,CHIP 470 5% 1/10W
R310 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R311 1-249-403-11 CARBON 68 5% 1/4W F
R315 1-216-107-00 RES,CHIP 270K 5% 1/10W
R317 1-216-019-00 RES,CHIP 56 5% 1/10W
R318 1-216-013-00 RES,CHIP 33 5% 1/10W
R319 1-216-113-00 RES,CHIP 470K 5% 1/10W
R320 1-216-113-00 RES,CHIP 470K 5% 1/10W
R322 1-216-113-00 RES,CHIP 470K 5% 1/10W
R323 1-216-037-00 RES,CHIP 330 5% 1/10W
R330 1-216-019-00 RES,CHIP 56 5% 1/10W
R333 1-216-019-00 RES,CHIP 56 5% 1/10W
R340 1-216-019-00 RES,CHIP 56 5% 1/10W
R351 1-219-742-11 CARBON 47 5% 1/2W
R361 1-215-395-00 METAL 82 1% 1/4W
<SPARK GAP>
SG001 1-519-422-11 GAP, SPARK
SG002 1-576-354-21 GAP, DISCHARGE
SG101 1-576-354-21 GAP, DISCHARGE
SG201 1-576-354-21 GAP, DISCHARGE
SG301 1-576-354-21 GAP, DISCHARGE
<CRYSTAL>
X001 1-781-472-21 VIBRATOR, CERAMIC (8MHz)
*******************************************************************************
A
