REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified
¡
marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-G400
7-5
D
* A-1346-879-B D BOARD, COMPLETE
****************************
1-533-223-11 HOLDER, FUSE (F601)
3-710-578-01 COVER, VOLUME, 6 MOLD (RV901)
4-047-285-01 SHEET, INSULATING (Q505)
4-382-854-01 SCREW (M3X8), P, SW (+) (D614, D619,
IC401, IC502, IC604, IC605, IC609, IC610,
IC703, Q506, Q511, Q512, Q513, Q605,
Q704, Q705, Q901, Q902, R510)
4-382-854-11 SCREW (M3X10), P, SW (+)
(D504, D620, D622, Q505)
4-382-854-21 SCREW (M3X14), P, SW (+) (IC702)
<CAPACITOR>
C401 1-128-730-91 ELECT 470uF 20% 25V
C402 1-106-228-00 MYLAR 0.22uF 10% 100V
C403 1-128-749-91 ELECT 220uF 20% 50V
C404 1-128-730-91 ELECT 470uF 20% 25V
C406 1-137-366-11 MYLAR 0.0022uF 5% 50V
C407 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C409 1-126-968-11 ELECT 100uF 20% 50V
C500 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C501 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C503 1-137-370-11 MYLAR 0.01uF 5% 50V
C504 1-137-368-11 MYLAR 0.0047uF 5% 50V
C505 1-128-729-91 ELECT 330uF 20% 25V
C506 1-127-810-51 ELECT MELF 22uF 20% 250V
C507 1-136-187-11 MYLAR 0.047uF 10% 250V
C508 1-117-959-11 FILM 4700pF 3% 1.8KV
C509 1-107-444-11 CERAMIC 100pF 5% 2KV
C510 1-136-684-51 MYLAR 0.0022uF 10% 100V
C511 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C512 1-102-114-00 CERAMIC 470pF 10% 50V
C513 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C514 1-137-368-11 MYLAR 0.0047uF 5% 50V
C515 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C516 1-126-382-11 ELECT 100uF 20% 16V
C517 1-163-263-11 CERAMIC CHIP 330pF 5% 50V
C518 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C520 1-163-024-00 CERAMIC CHIP 0.018uF 10% 50V
C521 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C522 1-126-965-11 ELECT 22uF 20% 50V
C523 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C524 1-126-382-11 ELECT 100uF 20% 16V
C525 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C527 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C528 1-130-489-00 MYLAR 0.033uF 5% 50V
C529 1-137-370-11 MYLAR 0.01uF 5% 50V
C530 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C531 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C532 1-107-906-11 ELECT 10uF 20% 50V
C533 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C534 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C535 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C536 1-107-665-11 ELECT 0.47uF 20% 400V
C537 1-107-770-11 FILM 0.16uF 3% 400V
C538 1-107-651-11 ELECT 4.7uF 20% 250V
C539 1-117-673-11 FILM 1.5uF 5% 250V
C540 1-107-888-11 ELECT 47uF 20% 25V
C541 1-109-844-11 FILM 0.68uF 5% 250V
C542 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C543 1-117-665-11 FILM 0.33uF 5% 250V
C544 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C545 1-117-661-71 FILM 0.15uF 5% 250V
C546 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C547 1-119-860-11 FILM 0.082uF 5% 250V
C548 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C549 1-117-953-91 FILM 0.033uF 5% 400V
C550 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C551 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C553 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C554 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C555 1-137-194-81 MYLAR 0.47uF 5% 50V
C556 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C557 1-126-935-11 ELECT 470uF 20% 16V
C558 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C559 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C560 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C562 1-163-001-11 CERAMIC CHIP 220pF 10% 50V
C563 1-113-340-11 ELECT 47uF 20% 25V
C564 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C565 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C608 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C609 1-117-703-11 CERAMIC 0.0047uF 99% 250V
C610 1-117-769-91 CERAMIC 680pF 10% 2KV
C611 1-125-483-11 ELECT(BLOCK) 470uF 20% 400V
C612 1-117-953-91 FILM 0.033uF 5% 400V
C613 1-104-664-11 ELECT 47uF 20% 25V
C614 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C615 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C616 1-102-228-00 CERAMIC 470pF 10% 500V
C617 1-117-769-91 CERAMIC 680pF 10% 2KV
C618 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C619 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C620 1-128-551-11 ELECT 22uF 20% 25V
C621 1-131-723-21 ELECT(BLOCK) 220uF 20% 250V
C622 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C623 1-107-933-11 ELECT 100uF 20% 100V
C624 1-104-666-11 ELECT 220uF 20% 25V
C625 1-115-789-11 ELECT 0.001F 20% 25V
C626 1-115-791-11 ELECT 0.0018F 20% 25V
C627 1-115-789-11 ELECT 0.001F 20% 25V
C628 1-107-890-11 ELECT 2200uF 20% 25V
C629 1-126-935-11 ELECT 470uF 20% 16V
C630 1-126-935-11 ELECT 470uF 20% 16V
C631 1-128-526-11 ELECT 100uF 20% 25V
C632 1-104-653-11 ELECT 220uF 20% 16V
C633 1-126-934-11 ELECT 220uF 20% 10V
C634 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C635 1-126-965-11 ELECT 22uF 20% 50V
C6360 1-113-900-51 CERAMIC 470pF 10% 250V
C6370 1-113-900-51 CERAMIC 470pF 10% 250V
To Next Page
