REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified
¡
marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-G400
7-6
D
C6380 1-104-708-51 MYLAR 0.47uF 20% 250V
C640 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C641 1-163-007-11 CERAMIC CHIP 680pF 10% 50V
C642 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C644 1-136-187-11 MYLAR 0.047uF 10% 250V
C645 1-126-934-11 ELECT 220uF 20% 16V
C646 1-107-882-91 ELECT 100uF 20% 16V
C647 1-107-882-91 ELECT 100uF 20% 16V
C648 1-126-964-11 ELECT 10uF 20% 50V
C650 1-162-117-00 CERAMIC 100pF 10% 500V
C653 1-126-942-61 ELECT 1000uF 20% 25V
C654 1-104-666-11 ELECT 220uF 20% 25V
C656 1-104-664-11 ELECT 47uF 20% 25V
C657 1-162-318-11 CERAMIC 0.001uF 10% 500V
C658 1-162-815-11 CERAMIC 47pF 5% 500V
C659 1-136-177-00 MYLAR 1uF 5% 50V
C701 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C703 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C704 1-130-495-00 MYLAR 0.1uF 5% 50V
C705 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C706 1-130-495-00 MYLAR 0.1uF 5% 50V
C707 1-126-942-61 ELECT 1000uF 20% 25V
C708 1-126-942-61 ELECT 1000uF 20% 25V
C711 1-163-113-00 CERAMIC CHIP 68pF 5% 50V
C712 1-163-113-00 CERAMIC CHIP 68pF 5% 50V
C713 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C714 1-126-960-11 ELECT 1uF 20% 50V
C716 1-136-177-00 MYLAR 1uF 5% 50V
C717 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C718 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C719 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C720 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C721 1-128-562-11 ELECT 47uF 20% 100V
C723 1-128-561-91 ELECT 33uF 20% 100V
C724 1-162-134-11 CERAMIC 470pF 10% 2KV
C725 1-126-965-11 ELECT 22uF 20% 50V
C726 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C727 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C728 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C729 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C730 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C731 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C732 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C901 1-104-665-11 ELECT 100uF 20% 25V
C902 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C903 1-107-904-11 ELECT 3.3uF 20% 50V
C904 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C905 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C906 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C907 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C908 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C909 1-104-665-11 ELECT 100uF 20% 25V
C910 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C911 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C912 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C913 1-119-748-11 ELECT 33uF 20% 400V
C914 1-136-187-11 MYLAR 0.047uF 10% 250V
C915 1-137-367-11 MYLAR 0.0033uF 5% 50V
C916 1-117-665-11 FILM 0.33uF 5% 250V
C917 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C918 1-117-626-11 FILM 2000pF 3% 1.2KV
C919 1-115-349-51 CERAMIC 0.01uF 2KV
C920 1-115-349-51 CERAMIC 0.01uF 2KV
C921 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C922 1-126-963-11 ELECT 4.7uF 20% 50V
C923 1-126-964-11 ELECT 10uF 20% 50V
C924 1-104-665-11 ELECT 100uF 20% 25V
C925 1-137-370-11 MYLAR 0.01uF 5% 50V
C926 1-106-220-00 MYLAR 0.1uF 10% 100V
C927 1-106-351-00 MYLAR 0.0022uF 99% 200V
C929 1-126-965-11 ELECT 22uF 20% 50V
C930 1-137-370-11 MYLAR 0.01uF 5% 50V
C931 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C1006 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1013 1-126-926-11 ELECT 1000uF 20% 10V
C1024 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C1025 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C1026 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1030 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C1031 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1036 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1037 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1038 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1042 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1046 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1047 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1050 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1056 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1057 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1061 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1062 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1063 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1064 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
<CONNECTOR>
CN501*1-580-798-11 CONNECTOR PIN (DY) 6P
CN600*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN601*1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN603*1-564-510-11 PLUG, CONNECTOR 7P
CN701*1-564-511-11 PLUG, CONNECTOR 8P
CN702* 1-564-506-11 PLUG, CONNECTOR 3P
CN1001* 1-508-879-11 BASE POST
CN1002* 1-564-511-11 PLUG, CONNECTOR 8P
CN1003* 1-564-515-11 PLUG, CONNECTOR 12P
CN1004* 1-564-509-11 PLUG, CONNECTOR 6P
CN1005 1-793-585-11 PIN, CONNECTOR (PC BOARD) 15P
CN1006 1-793-586-11 PIN, CONNECTOR (PC BOARD) 15P
To Next Page
