5
Getting Started
-EN
EN
Rear of TV
When connecting video equipment to the
… (video input) jack
Do not connect video equipment to the … (video input) jacks at the front and the rear of your TV simultaneously; otherwise the picture
will not be displayed properly on the screen.
: Signal flow
Connecting audio/video equipment using the Ú (monitor output) jack
When recording through the Ú (monitor output) jack
Do not change the channel or video input while recording with a VCR; otherwise the channel or video input you are recording also will be
changed.
to video
and audio
inputs
Rear of TV
to antenna socket
to antenna
output
VCR
to video
and audio
outputs
: Signal flow
to antenna socket
to antenna
output
VCR
Audio system
or
p KV-J21MF2J
to
…
(video input)
(video) and
(audio) inputs
to
Ú
(monitor output)
(video) and
(audio) inputs
p KV-2199M5J/J14M1J
p KV-2199M5J/J14M1J
p KV-J21MF2J
To Next Page
