— 22 —
KV-24FV12/25FV12/25FV12A/25FV12C
Reg # ITEM FUNCTION RANGE
FIX
DATA NTSC PAL M PAL N VIDEO RF
AVERAGE
DATA
1 HSIZ Horizontal Size Adjustment 0-63 35 35 35
38
2 HPOS Horizontal Position Adjustment 0-63 33 33 33
21
3 VBOW Vertical Line Bowing Adj. 0-15 5 5 5
9
4 VANG Vertical line Bowing Slant Adj. 0-15 7 7 7
5
5 TRAP Horizontal Trapezoid Adj. 0-15 7 7 7
7
6 PAMP Horizontal PIN Distortion Adj. 0-63 7 7 7
32
7 UPIN Upper PIN Distortion Adj. 0-63 36 36 36
39
8 LPIN Lower PIN Distortion Adj. 0-63 36 36 36
39
9 VM Velocity Modulation On/Off 0,1
0
10 BLKO Vertical Blanking On/Off 0,1 0
0
11 VMLV Velocity Modulation Level 0-3
2
12 AGN2 Aging 2 0,1 0
0
13 REFP Reference Pulse Position 0,1 0
0
14 VBLK Vertical Blanking On/Off 0,1 0
0
15 JPSW 0,1 0
0
16 VSIZ Vertical Size Adjustment 0-63 40 47 47
49
17 VPOS Vertical Position Adj. 0-63 32 32 32
32
18 VLIN Vertical Linearity Adj. 0-15 7 7 7
6
19 SCOR Vertical "S" Correction Adjustment 0-15 6 6 6
8
20 VZOM 16:9 CRT Z Mode On/Off 0,1 0
0
21 EHT Vertical High-Voltage Correction 0-15 6
6
22 ASP Aspect Ratio Control 0-63 47
47
23 SCRL 16:9 CRT Z Mode Trans. Scroll 0-63 31
31
24 HBLK Horizontal Blanking On/Off 0,1 1
1
25 LBLK Left Blanking Adjustment 0-15 11
12
26 RBLK Right Blanking Adjustment 0-15 8
5
27 VUSN V Saw Waveform Compress 0,1 0
0
28 HDW Horizontal Drive Pulse Width 0,1 1
1
29 EWDC "Parabola" EW/ D.C. Adjustment 0.1 0
0
30 LVLN Lower Screen BTM Vertical Line Adj. 0-15 0
0
31 UVLN Upper Screen BTM Vertical Line Adj. 0-15 0
0
32 HTRAP Horizontal Trapezoid Adj. 0,1 ****
0
33 RDRV R Output Drive Control 0-63 31
36
34 GDRV G Output Drive Control 0-63 21
26
35 BDRV B Output Drive Control 0-63 21
25
36 RCUT R Output Cutoff Control 0-15 10
8
37 GCUT G Output Cutoff Control 0-15 6
6
38 BCUT B Output Cutoff Control 0-15 6
7
39 DCOL Dynamic Color On/Off 0,1 0
1
40 SHUE Sub HUE 0-31 15
15
41 SCOL Sub Color 0-31 15 15 15
15
42 SBRT Sub BRIGHTNESS 0-31 16
15
43 RON R Output On/Off 0,1 1
1
44 GON G Output On/Off 0,1 1
1
45 BON B Output On/Off 0,1 1
1
46 AXPL Axis PAL 0,1 0
0
47 AXNT Axis NTSC 0,1 1
0
48 CBPF Chroma BPF On/Off 0,1 1
1
49 CTRP Y TRAP FILTER On/Off 0,1 1
1
50 COFF Color On/Off 0,1 0
0
51 KOFF Set Color Killer 0,1 0
0
52 SSHP Sub SHARPNESS 0-15 5
7
53 SHPF SHARPNESS Circuit Fo 0,1
1
54 PREL Pre-Shoot / Over-Shoot 0,1 1
1
55 Y-DC DC Transmission Ratio Switching 0,1
1
56 GAMM Gamma Correction Amnt 0-3
1
57 ABLM ABL Mode Switching 0,1 1
1
58 VTH ABL CD VHT Switching 0,1 1
1
59 YDEL Y Delay Time Control 0-15 7
7
60 NCOL No Color ID 0,1 1
1
61 FSC FSC Out On/Off 0,1 1
1
62 K-ID Killer ID Control On/Off 0,1 0
0
63 HOSC Horizontal VCO Oscillation Freq. 0-15 7
7
Palette mode controls this register
Palette mode controls this register
Palette mode controls this register
Palette mode controls this register
Palette mode controls this register
Adjustment Items
