REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
RESISTOR
R3001 1-249-417-11 CARBON 1K 5% 1/4W
R3014 1-247-807-31 CARBON 100 5% 1/4W
SWITCH
S3006 1-786-338-12 SWITCH, TACTILE
HS
* A-1415-674-A HS BOARD, MOUNTED
(ALL EXCEPT KV-29FA310LN/29FA310LS)
CAPACITOR
C1001 1-104-665-11 ELECT 100µF 20% 25V
C1234 1-126-960-11 ELECT 1µF 20% 50V
C1235 1-126-960-11 ELECT 1µF 20% 50V
DIODE
D1001 8-719-929-15 DIODE HZS9.1NB2
D1002 8-719-070-80 DIODE LNK0120022G
D1003 8-719-929-15 DIODE HZS9.1NB2
D1004 8-719-109-89 DIODE RD5.6ESB2
D1005 8-719-109-89 DIODE RD5.6ESB2
D1233 8-719-108-12 DIODE RD9.1EW
D1235 8-719-108-12 DIODE RD9.1EW
D1236 8-719-108-12 DIODE RD9.1EW
IC
IC1001 8-742-212-20 HYB IC SBX3081-71
JACK
J1231 1-794-048-11 JACK, PIN 3P
RESISTOR
R1004 1-249-417-11 CARBON 1K 5% 1/4W
R1007 1-247-807-31 CARBON 100 5% 1/4W
R1008 1-249-427-11 CARBON 6.8K 5% 1/4W
R1009 1-249-421-11 CARBON 2.2K 5% 1/4W
R1010 1-249-416-11 CARBON 820 5% 1/4W
R1011 1-249-415-11 CARBON 680 5% 1/4W
R1201 1-249-419-11 CARBON 1.5K 5% 1/4W
R1202 1-249-421-11 CARBON 2.2K 5% 1/4W
R1203 1-249-427-11 CARBON 6.8K 5% 1/4W
R1234 1-247-804-11 CARBON 75 5% 1/4W
R1235 1-249-409-11 CARBON 220 5% 1/4W
R1236 1-249-441-11 CARBON 100K 5% 1/4W
R1237 1-249-409-11 CARBON 220 5% 1/4W
R1238 1-249-441-11 CARBON 100K 5% 1/4W
SWITCH
S1001 1-692-431-21 SWITCH, TACTILE
S1002 1-692-431-21 SWITCH, TACTILE
S1003 1-692-431-21 SWITCH, TACTILE
S1004 1-692-431-21 SWITCH, TACTILE
S1005 1-692-431-21 SWITCH, TACTILE
S1006 1-692-431-21 SWITCH, TACTILE
S1007 1-762-816-11 SWITCH, TACTILE
S1008 1-762-816-11 SWITCH, TACTILE
HU
* A-1415-631-A HU (VAR) BOARD, MOUNTED
CAPACITOR
C2234 1-137-194-81 FILM 0.47µF 5% 50V
C2235 1-137-194-81 FILM 0.47µF 5% 50V
DIODE
D301 8-719-108-12 DIODE RD9.1EW
D2235 8-719-108-12 DIODE RD9.1EW
D2236 8-719-108-12 DIODE RD9.1EW
D2240 8-719-110-17 DIODE RD10ESB2
D2241 8-719-110-17 DIODE RD10ESB2
JACK
J2231 1-794-048-11 JACK, PIN 3P
HR
HS
HU
