Additional Information
Here are some simple solutions to problems which may affect the picture and sound.
• If you continue to have these problems, have your TV serviced by qualified personnel.
• NEVER open the casing yourself.
Troubleshooting
Problem Suggested remedy
No picture (screen is dark), no sound • Plug the TV in.
• Press the button on the front of the TV.
• If the indicator is on press the button or a numbered
button on the remote control.
• Check the aerial connection.
• Turn the TV off for 3 or 4 seconds and then turn it on again
using the button on the front of the TV.
Poor or no picture (screen is dark), but
good sound.
• Using the MENU system, select the Picture
Adjustment display. Adjust the brightness, picture and colour
balance levels.
• From the Picture Adjustment display select RESET to return
to the factory settings.
Good picture, no sound
• Press the button on the remote control.
• If is displayed on the screen, press the button on the
remote control.
No colour on colour programmes • Using the MENU system, select the Picture Adjustment
display and adjust the colour setting.
• From the Picture Adjustment display select RESET to return
to the factory settings.
Distorted picture when changing
programmes or selecting Teletext
• Turn off any equipment connected to the scart connectors on
the rear of the TV.
Remote control does not function • Replace the batteries.
The standby indicator on the TV
flashes
• Contact your nearest Sony service centre.
Interference on picture from external
equipment
• Reduce sharpness level.
/
22
Additional Information
Specifications
TV system
B/G/H, D/K
Colour system
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Channel coverage
See the ‘Channel Display Table’ below.
Picture tube
FD Trinitron, Approx. 72cm (29 inches)
Rear Terminals
/ 21-pin Euro connector (CENELEC standard) including audio/
video input, RGB input, TV audio/video output.
/ 21-pin Euro connector (CENELEC standard) including audio/
video input, S-video input, Selectable audio/video output.
/ 21-pin Euro connector (CENELEC standard) including audio/
video input, S-video input, Monitor audio/video output.
L/G/S/I RCA connectors, variable output for audio signals.
R/D/D/D
RF In
Front Terminals
Video input -phono jacks
Audio inputs - phono jacks
S video input - 4 pin DIN
Headphones jack - minijack stereo
1
1
2
s
2
3
s
3
4
4
s
4
Sound output
Left/Right: 2x20W (Music Power)
2x10W (RMS)
Sub woofer: 30W (Music Power)
15W (RMS)
Power consumption
121W
Dimensions (wxhxd)
Approx. 771x585x506mm
Weight
Approx. 51kg
Accessories supplied
RM-887 remote control (1)
IEC designated size AA batteries (2)
Optional accessory
TV Stand: SU-29FX2
Other features
Flat display Trinitron tube, noise reduction, graphic equaliser,
2000 page TEXT memory, personal ID, sleep timer,
NexTView.
Design and specifications are subject to change
without notice.
Channel Display Table
Receivable Channels Channel Displays
B/G/H E2..12, 21..69 C02..C12, C21..69
KABEL-TV (1) S1..S41 S01..S41
KABEL-TV (2) S01..S05 S42..S46
M1..M10 S01..S10
U1..U10 S11.S20
ITALIEN A, B..H, H1, H2 C13, C14..C20, C11, C12
D/K R01..R12, R21..R69 C01..C12, C21..C69
S01..S05 S42..S46
