Sony Trinitron KV-29FX66E - Board-Specific Parts Lists

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 49 -
A
*A-1647-043-A H2 Board, Complete
< CAPACITOR >
C2906 1-126-960-11 ELECT 1UF 20.00% 50V
C2907 1-126-960-11 ELECT 1UF 20.00% 50V
C2913 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C2914 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
< CONNECTOR >
CN2900 1-779-947-11 TERMINAL BLOCK, S
CN2906 *1-564-524-11 PLUG, CONNECTOR 9P
CN2908 1-564-521-11 PLUG, CONNECTOR 6P
< JACK >
J2900 1-750-264-11 JACK
< COIL >
L0904 1-410-119-11 INDUCTOR 1MH
L2900 1-535-143-61 LEAD, JUMPER (5.0MM)
L2901 1-535-143-61 LEAD, JUMPER (5.0MM)
L2902 1-535-143-61 LEAD, JUMPER (5.0MM)
L2903 1-535-143-61 LEAD, JUMPER (5.0MM)
< RESISTOR >
R912 1-535-143-61 LEAD, JUMPER (5.0MM)
R0901 1-249-427-11 CARBON 6.8K 5% 1/4W
R0902 1-249-429-11 CARBON 10K 5% 1/4W
R0911 1-249-419-11 CARBON 1.5K 5% 1/4W
R0913 1-247-843-11 CARBON 3.3K 5% 1/4W
R0914 1-249-431-11 CARBON 15K 5% 1/4W
R2903 1-249-406-11 CARBON 120 5% 1/4W
R2904 1-249-406-11 CARBON 120 5% 1/4W
R2909 1-247-895-91 CARBON 470K 5% 1/4W
R2910 1-247-895-91 CARBON 470K 5% 1/4W
R2915 1-249-406-11 CARBON 120 5% 1/4W
R2916 1-249-406-11 CARBON 120 5% 1/4W
R2917 1-249-412-11 CARBON 390 5% 1/4W
R2918 1-249-412-11 CARBON 390 5% 1/4W
< SWITCH >
S0900 1-692-979-11 SWITCH, TACTILE
S0901 1-692-979-11 SWITCH, TACTILE
S0902 1-692-979-11 SWITCH, TACTILE
*A-1625-000-A F4 Board, Complete
*4-374-846-01 COVER, CAPACITOR, CAP TYPE
< CAPACITOR >
C6991 £ 1-113-924-11 CERAMIC 0.0047UF 20.00% 250V
< CONNECTOR >
CN6991 1-580-843-11 PIN, CONNECTOR (POWER)
CN6992 *1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
CN6993 1-695-915-11 TAB (CONTACT)
< FUSE >
F6991 £ 1-576-232-11 FUSE (H.B.C.) 5A/250V
*1-533-725-11 HOLDER, FUSE (F6991)
< RESISTOR >
R6991 1-202-719-00 SOLID 1M 10% 1/2W
< SWITCH >
S6991 £ 1-571-433-31 SWITCH (AC POWER)
< VARISTOR >
VD6991 1-803-830-11 VARISTOR (ERZV14D621)
*A-1646-243-A H1 Board, Complete
4-206-220-01 HOLDER, LED
< CAPACITOR >
C0992 1-104-665-11 ELECT 100UF 20.00% 25V
C0993 1-102-114-00 CERAMIC 470PF 10.00% 50V
C0994 1-102-129-00 CERAMIC 0.01UF 10.00% 50V
< CONNECTOR >
CN0991 *1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D0991 8-719-109-89 DIODE RD5.6ESB2
D0993 8-719-082-12 DIODE TLHK5190
< IC >
IC0991 8-742-180-30 HYB IC SBX3081-51(30)
< RESISTOR >
R0992 1-247-807-31 CARBON 100 5% 1/4W
*A-1632-952-A A Board, Complete
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C1001 1-126-933-11 ELECT 100UF 20.00% 16V
C1002 1-126-964-11 ELECT 10UF 20.00% 50V
C1004 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
H1H2 F4
