REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 62 -
R6048 1-215-481-00 METAL 330K 1% 1/4W
R6049 1-208-805-11 METAL CHIP 9.1K 0.5% 1/10W
R6050 1-208-758-11 METAL CHIP 100 0.5% 1/10W
R6054 1-211-964-91 RES-CHIP 33 0.5% 1/10W
R6056 1-216-295-91 SHORT 0
R6101 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6102 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6103 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6104 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6105 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6106 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6107 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6108 1-216-821-11 RES-CHIP 1K 5% 1/16W
R6109 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R6110 1-216-821-11 RES-CHIP 1K 5% 1/16W
< RELAY >
RY6001 £ 1-755-395-11 RELAY (AC POWER)
RY6002 £ 1-755-389-11 RELAY (AC POWER)
< TRANSFORMER >
T6002 £ 1-437-443-11 TRANSFORMER, PIT
T6003 £ 1-424-896-11 TRANSFORMER, LINE FILTER
T6101 £ 1-437-483-11 TRANSFORMER, STANDBY
< THERMISTOR >
TH6002 £ 1-803-541-11 THERMISTOR
*A-1638-158-A C Board, Complete
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C7303 1-162-909-91 CERAMIC CHIP 4PF 0.25PF 50V
C7305 1-136-207-11 MYLAR 0.047UF 10.00% 400V
C7306 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C7309 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C7310 1-163-113-00 CERAMIC CHIP 68PF 5.00% 50V
C7325 1-162-909-91 CERAMIC CHIP 4PF 0.25PF 50V
C7326 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C7330 1-136-207-11 MYLAR 0.047UF 10.00% 400V
C7333 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C7334 1-163-113-00 CERAMIC CHIP 68PF 5.00% 50V
C7350 1-104-664-91 ELECT 47UF 20.00% 50V
C7351 1-162-909-91 CERAMIC CHIP 4PF 0.25PF 50V
C7352 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C7354 1-126-933-11 ELECT 100UF 20.00% 16V
C7355 1-107-967-11 ELECT 1UF 20.00% 400V
C7356 1-136-207-11 MYLAR 0.047UF 10.00% 400V
C7359 1-163-035-00 CERAMIC CHIP 0.047UF 50V
G
C7360 1-163-113-00 CERAMIC CHIP 68PF 5.00% 50V
C7378 1-162-116-00 CERAMIC 680PF 10.00% 2KV
C7379 1-162-114-00 CERAMIC 0.0047UF 2KV
C7385 1-162-913-91 CERAMIC CHIP 8PF 0.50PF 50V
C7388 1-162-913-91 CERAMIC CHIP 8PF 0.50PF 50V
C7391 1-162-913-91 CERAMIC CHIP 8PF 0.50PF 50V
< CONNECTOR >
CN7300 *1-564-508-11 PLUG, CONNECTOR 5P
CN7301 *1-564-512-11 PLUG, CONNECTOR 9P
CN7311 1-695-915-11 TAB (CONTACT)
CN7333 1-695-915-11 TAB (CONTACT)
< DIODE >
D7300 8-719-911-19 DIODE 1SS119-25
D7325 8-719-911-19 DIODE 1SS119-25
D7350 8-719-911-19 DIODE 1SS119-25
D7375 8-719-991-33 DIODE 1SS133T-77
D7376 8-719-991-33 DIODE 1SS133T-77
< IC >
IC7300 8-759-360-83 IC TDA6111Q/N4
IC7325 8-759-360-83 IC TDA6111Q/N4
IC7350 8-759-360-83 IC TDA6111Q/N4
< SOCKET >
J7375 £ 1-251-732-11 SOCKET, CRT
< COIL >
L7375 1-410-671-31 INDUCTOR 47UH
L7376 £ 1-532-637-00 LINK, IC 1A/150V
L7378 1-414-934-21 INDUCTOR 10UH
< TRANSISTOR >
Q7350 8-729-901-06 TRANSISTOR DTA144EK
Q7352 8-729-421-19 TRANSISTOR UN2213
Q7353 8-729-421-19 TRANSISTOR UN2213
Q7354 8-729-901-06 TRANSISTOR DTA144EK
Q7355 8-729-421-19 TRANSISTOR UN2213
< RESISTOR >
R7300 1-249-417-11 CARBON 1K 5% 1/4W
R7302 1-535-143-61 LEAD, JUMPER (5.0MM)
R7303 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7304 1-202-565-81 RES-SOLID 470 20% 1/2W
R7305 1-215-903-11 METAL OXIDE 68K 5% 2W
R7306 1-535-143-61 LEAD, JUMPER (5.0MM)
R7309 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R7325 1-249-417-11 CARBON 1K 5% 1/4W
R7327 1-535-143-61 LEAD, JUMPER (5.0MM)
