Sony Trinitron KV-29FX66E - Page 65

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 64 -
C8836 1-123-024-21 ELECT 33UF 160V
C8837 1-106-375-12 MYLAR 0.022UF 10.00% 250V
C8840 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C8841 1-126-947-11 ELECT 47UF 20.00% 25V
C8844 1-115-513-21 FILM 0.18UF 5.00% 250V
C8851 1-162-131-11 CERAMIC 220PF 10.00% 2KV
C8852 1-162-129-00 CERAMIC 150PF 10.00% 2KV
C8853 1-129-898-00 FILM 0.0022UF 5.00% 630V
C8855 1-136-205-11 MYLAR 0.022UF 10.00% 400V
C8856 1-102-030-00 CERAMIC 330PF 10.00% 500V
C8860 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8861 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C8869 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
< CONNECTOR >
CN8600 *1-564-509-11 PLUG, CONNECTOR 6P
CN8601 *1-564-506-11 PLUG, CONNECTOR 3P
CN8611 *1-785-270-12 PIN, DY CONNECTOR (PC BOARD)
CN8612 *1-564-511-51 PLUG, CONNECTOR 8P
CN8614 *1-564-508-11 PLUG, CONNECTOR 5P
CN8616 1-695-915-11 TAB (CONTACT)
CN8620 *1-764-333-11 PLUG, CONNECTOR 10P
CN8810 *1-564-510-11 PLUG, CONNECTOR 7P
< DIODE >
D8102 8-719-081-97 DIODE MMDL914T1
D8103 8-719-081-97 DIODE MMDL914T1
D8104 8-719-081-97 DIODE MMDL914T1
D8105 8-719-081-97 DIODE MMDL914T1
D8107 8-719-081-97 DIODE MMDL914T1
D8108 8-719-921-40 DIODE MTZJ-4.7C
D8128 8-719-081-97 DIODE MMDL914T1
D8129 8-719-081-97 DIODE MMDL914T1
D8132 8-719-081-97 DIODE MMDL914T1
D8133 8-719-081-97 DIODE MMDL914T1
D8198 1-535-143-61 LEAD, JUMPER (5.0MM)
D8199 8-719-081-97 DIODE MMDL914T1
D8611 8-719-081-97 DIODE MMDL914T1
D8612 8-719-081-97 DIODE MMDL914T1
D8803 8-719-908-03 DIODE GP08D
D8805 8-719-302-43 DIODE EL1Z
D8806 8-719-979-85 DIODE EGP20G
D8807 8-719-085-12 DIODE BYV98-200-RAS 15/12
D8808 8-719-085-12 DIODE BYV98-200-RAS 15/12
D8811 8-719-110-41 DIODE RD15ES-B2
D8818 8-719-109-89 DIODE RD5.6ESB2
D8819 8-719-050-38 DIODE M1MA152WK-T1
D8820 8-719-081-97 DIODE MMDL914T1
D8851 8-719-970-87 DIODE ERA38-06
D8856 8-719-081-97 DIODE MMDL914T1
D
D8857 8-719-110-41 DIODE RD15ES-B2
D8858 8-719-081-97 DIODE MMDL914T1
< FERRITE BEAD >
FB8807 1-410-397-21 FERRITE 1.1UH
< IC >
IC8100 8-759-450-95 IC LM393N
IC8101 8-759-450-95 IC LM393N
IC8102 8-759-638-79 IC NJM3404AD-W
IC8103 8-759-450-95 IC LM393N
< COIL >
L8801 1-410-397-21 FERRITE 1.1UH
L8802 1-410-397-21 FERRITE 1.1UH
L8803 1-410-397-21 FERRITE 1.1UH
L8805 1-408-947-00 INDUCTOR 2.2MH
L8851 1-535-143-61 LEAD, JUMPER (5.0MM)
< FILTER >
LF8801 1-406-985-11 INDUCTOR 2.2MH
LF8851 1-406-674-11 INDUCTOR 3.3MH
< TRANSISTOR >
Q8100 8-729-010-29 TRANSISTOR MSD601-RST1
Q8101 8-729-010-29 TRANSISTOR MSD601-RST1
Q8102 8-729-010-29 TRANSISTOR MSD601-RST1
Q8103 8-729-010-29 TRANSISTOR MSD601-RST1
Q8104 8-729-010-29 TRANSISTOR MSD601-RST1
Q8105 8-729-010-29 TRANSISTOR MSD601-RST1
Q8106 8-729-010-29 TRANSISTOR MSD601-RST1
Q8107 8-729-010-29 TRANSISTOR MSD601-RST1
Q8108 8-729-010-05 TRANSISTOR MSB709-RT1
Q8110 8-729-010-05 TRANSISTOR MSB709-RT1
Q8112 8-729-010-29 TRANSISTOR MSD601-RST1
Q8113 8-729-010-29 TRANSISTOR MSD601-RST1
Q8115 8-729-010-05 TRANSISTOR MSB709-RT1
Q8118 8-729-010-29 TRANSISTOR MSD601-RST1
Q8119 8-729-010-05 TRANSISTOR MSB709-RT1
Q8120 8-729-010-05 TRANSISTOR MSB709-RT1
Q8122 8-729-010-05 TRANSISTOR MSB709-RT1
Q8123 8-729-010-05 TRANSISTOR MSB709-RT1
Q8125 8-729-010-29 TRANSISTOR MSD601-RST1
Q8126 8-729-010-05 TRANSISTOR MSB709-RT1
Q8127 8-729-010-05 TRANSISTOR MSB709-RT1
Q8128 8-729-010-29 TRANSISTOR MSD601-RST1
Q8132 8-729-421-19 TRANSISTOR UN2213
Q8135 8-729-010-29 TRANSISTOR MSD601-RST1
Q8136 8-729-010-05 TRANSISTOR MSB709-RT1
