The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
– 45 –
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
KV-G14M2
RM-869
D611 8-719-510-26 DIODE D1NL20
D801 8-719-945-80 DIODE ERC06-15S
D851 8-719-302-43 DIODE EL1Z
D852 8-719-028-72 DIODE RGP02-17EL-6433
D853 8-719-302-43 DIODE EL1Z
D855 8-719-302-43 DIODE EL1Z
D857 8-719-908-03 DIODE GP08D
D858 8-719-908-03 DIODE GP08D
D860 8-719-911-19 DIODE 1SS119-25
D901 1-810-039-11 LED UNIT
D1201 8-719-121-24 DIODE RD9.1ESL
D1202 8-719-121-24 DIODE RD9.1ESL
D1207 8-719-121-24 DIODE RD9.1ESL
D1208 8-719-121-24 DIODE RD9.1ESL
D1504 8-719-911-19 DIODE 1SS119-25
D1505 8-719-109-81 DIODE RD4.7ESB2
<FERRITE BEAD>
FB101 1-410-397-21 FERRITE 1.1UH
FB102 1-410-397-21 FERRITE 1.1UH
FB103 1-410-397-21 FERRITE 1.1UH
FB601 1-410-397-21 FERRITE 1.1UH
FB603 1-410-397-21 FERRITE 1.1UH
FB610 1-410-397-21 FERRITE 1.1UH
FB612 1-410-397-21 FERRITE 1.1UH
<IC>
IC001 8-752-891-28 IC CXP85220A-058S (F35430206)
IC001 8-752-891-61 IC CXP85220A-060S (F35430296)
IC002 8-759-805-37 IC L78LR05D-MA
IC003 8-759-370-33 IC ST24C04FB6
IC004 8-742-041-12 HYB IC SBX1981-11(12)
IC100 8-759-157-40 IC UPC574J
IC203 8-759-339-60 IC TA8248K
IC300 8-759-365-25 IC TDA8374A
IC351 8-759-288-85 IC TDA4665T-T
IC354 8-759-251-56 IC TDA8395T
IC401 8-759-800-65 IC LA7910
IC521 8-759-195-63 IC PQ09RE11
IC551 8-759-801-98 IC LA7830
IC601 8-749-014-00 IC STR-S6707N
IC602 8-749-921-89 IC SE115N
IC603 ! 8-749-010-64 PHOTO COUPLER PC123F2
IC801 8-759-100-96 IC UPC4558G2
IC1210 8-759-100-96 IC UPC4558G2
IC1211 8-759-711-23 IC NJM2234L
<JACK>
J251 1-770-785-11 JACK
J1201 1-779-849-11 JACK BLOCK, PIN 4P
J1202 1-779-205-11 JACK, PIN 2P
<CHIP CONDUCTOR>
JR050 1-216-295-91 SHORT 0
JR052 1-216-295-91 SHORT 0
JR101 1-216-295-91 SHORT 0
JR111 1-216-295-91 SHORT 0
JR112 8-719-041-97 DIODE MA113-(TX)
JR113 1-216-295-91 SHORT 0
JR114 1-208-291-11 RES,CHIP 4.7M 5% 1/10W
JR116 1-216-295-91 SHORT 0
JR117 1-216-295-91 SHORT 0
JR118 1-216-295-91 SHORT 0
JR124 1-216-295-91 SHORT 0
JR125 1-216-295-91 SHORT 0
JR126 1-216-295-91 SHORT 0
JR251 1-216-295-91 SHORT 0
<COIL>
L001 1-408-397-00 INDUCTOR 1UH
L002 1-410-509-11 INDUCTOR 10UH
L003 1-408-605-31 INDUCTOR 15UH
L101 1-410-470-11 INDUCTOR 10UH
L301 1-408-602-31 INDUCTOR 8.2UH
L401 1-410-498-11 INDUCTOR 1.2UH
L402 1-410-510-11 INDUCTOR 12UH
L403 1-410-510-11 INDUCTOR 12UH
L404 1-410-508-11 INDUCTOR 8.2UH
L405 1-410-508-11 INDUCTOR 8.2UH
L406 1-410-507-11 INDUCTOR 6.8UH
L407 1-410-511-11 INDUCTOR 15UH
L408 1-410-500-11 INDUCTOR 1.8UH
L409 1-410-501-11 INDUCTOR 2.2UH
L410 1-410-501-11 INDUCTOR 2.2UH
L411 1-410-502-11 INDUCTOR 2.7UH
L802 1-412-527-11 INDUCTOR 15UH
L805 1-460-046-11 COIL, HORIZONTAL LINEARITY
L807 1-459-348-51 COIL, VAR, FERRITE (HWC)
L808 1-412-553-11 INDUCTOR 3.3MMH
L821 1-406-677-11 INDUCTOR 0UH
L850 1-408-947-00 INDUCTOR 2.2MMH
<TRANSISTOR>
Q030 8-729-422-27 TRANSISTOR 2SD601A-Q
Q108 8-729-422-27 TRANSISTOR 2SD601A-Q
Q109 8-729-422-27 TRANSISTOR 2SD601A-Q
Q110 8-729-422-27 TRANSISTOR 2SD601A-Q
Q202 8-729-216-22 TRANSISTOR 2SA1162-G
Q207 8-729-216-22 TRANSISTOR 2SA1162-G
Q208 8-729-421-19 TRANSISTOR UN2213
Q210 8-729-424-67 TRANSISTOR UN2216
Q301 8-729-421-22 TRANSISTOR UN2211
Q303 8-729-422-27 TRANSISTOR 2SD601A-Q
Q402 8-729-922-66 TRANSISTOR 2SC2410SN
Q403 8-729-424-67 TRANSISTOR UN2216
Q404 8-729-424-67 TRANSISTOR UN2216
Q405 8-729-216-22 TRANSISTOR 2SA1162-G
Q406 8-729-216-22 TRANSISTOR 2SA1162-G
A
()
F35430206
F35430296
