The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
– 46 –
KV-G14M2
RM-869
Q407 8-729-216-22 TRANSISTOR 2SA1162-G
Q408 8-729-422-27 TRANSISTOR 2SD601A-Q
Q409 8-729-216-22 TRANSISTOR 2SA1162-G
Q410 8-729-216-22 TRANSISTOR 2SA1162-G
Q411 8-729-422-27 TRANSISTOR 2SD601A-Q
Q412 8-729-422-27 TRANSISTOR 2SD601A-Q
Q413 8-729-424-67 TRANSISTOR UN2216
Q414 8-729-422-27 TRANSISTOR 2SD601A-Q
Q415 8-729-424-67 TRANSISTOR UN2216
Q416 8-729-422-27 TRANSISTOR 2SD601A-Q
Q417 8-729-424-67 TRANSISTOR UN2216
Q418 8-729-424-67 TRANSISTOR UN2216
Q561 8-729-200-17 TRANSISTOR 2SA1091-O
Q801 8-729-140-50 TRANSISTOR 2SC3209LK
Q802 8-729-810-49 TRANSISTOR 2SD1877S-SONY-CA
Q902 8-729-421-19 TRANSISTOR UN2213
Q903 8-729-421-19 TRANSISTOR UN2213
Q1201 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1202 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1203 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1204 8-729-216-22 TRANSISTOR 2SA1162-G
Q1207 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1208 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1209 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1265 8-729-424-67 TRANSISTOR UN2216
Q1513 8-729-422-27 TRANSISTOR 2SD601A-Q
<RESISTOR>
R65 1-216-033-00 RES,CHIP 220 5% 1/10W
R001 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R002 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R003 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R004 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R007 1-216-073-00 RES,CHIP 10K 5% 1/10W
R008 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R009 1-216-049-91 RES,CHIP 1K 5% 1/10W
R010 1-216-049-91 RES,CHIP 1K 5% 1/10W
R012 1-216-017-91 RES,CHIP 47 5% 1/10W
R013 1-216-049-91 RES,CHIP 1K 5% 1/10W
R014 1-216-049-91 RES,CHIP 1K 5% 1/10W
R015 1-216-049-91 RES,CHIP 1K 5% 1/10W
R016 1-216-049-91 RES,CHIP 1K 5% 1/10W
R017 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R018 1-216-033-00 RES,CHIP 220 5% 1/10W
R019 1-216-101-00 RES,CHIP 150K 5% 1/10W
R021 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R022 1-216-295-91 SHORT 0
R025 1-216-295-91 SHORT 0
R026 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R027 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R028 1-216-025-91 RES,CHIP 100 5% 1/10W
R029 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R031 1-216-049-91 RES,CHIP 1K 5% 1/10W
R033 1-216-049-91 RES,CHIP 1K 5% 1/10W
R035 1-216-049-91 RES,CHIP 1K 5% 1/10W
R036 1-216-049-91 RES,CHIP 1K 5% 1/10W
R038 1-216-033-00 RES,CHIP 220 5% 1/10W
R040 1-216-033-00 RES,CHIP 220 5% 1/10W
R041 1-216-025-91 RES,CHIP 100 5% 1/10W
R042 1-216-039-00 RES,CHIP 390 5% 1/10W
R045 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R047 1-216-025-91 RES,CHIP 100 5% 1/10W
R048 1-216-025-91 RES,CHIP 100 5% 1/10W
R053 1-216-295-91 SHORT 0
R054 1-216-073-00 RES,CHIP 10K 5% 1/10W
R057 1-216-049-91 RES,CHIP 1K 5% 1/10W
R060 1-216-037-00 RES,CHIP 330 5% 1/10W
R061 1-216-049-91 RES,CHIP 1K 5% 1/10W
R062 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R063 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R066 1-216-033-00 RES,CHIP 220 5% 1/10W
R068 1-216-025-91 RES,CHIP 100 5% 1/10W
R071 1-216-037-00 RES,CHIP 330 5% 1/10W
R072 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R076 1-216-025-91 RES,CHIP 100 5% 1/10W
R077 1-216-025-91 RES,CHIP 100 5% 1/10W
R090 1-216-073-00 RES,CHIP 10K 5% 1/10W
R101 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R102 1-216-049-91 RES,CHIP 1K 5% 1/10W
R113 1-216-081-00 RES,CHIP 22K 5% 1/10W
R114 1-216-041-00 RES,CHIP 470 5% 1/10W
R115 1-216-081-00 RES,CHIP 22K 5% 1/10W
R116 1-216-081-00 RES,CHIP 22K 5% 1/10W
R117 1-216-081-00 RES,CHIP 22K 5% 1/10W
R118 1-216-081-00 RES,CHIP 22K 5% 1/10W
R119 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R120 1-216-109-00 RES,CHIP 330K 5% 1/10W
R131 1-216-464-11 METAL OXIDE 18K 5% 2W F
R180 1-216-033-00 RES,CHIP 220 5% 1/10W
R181 1-216-033-00 RES,CHIP 220 5% 1/10W
R182 1-216-033-00 RES,CHIP 220 5% 1/10W
R240 1-216-043-91 RES,CHIP 560 5% 1/10W
R241 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
R242 1-216-037-00 RES,CHIP 330 5% 1/10W
R243 1-216-073-00 RES,CHIP 10K 5% 1/10W
R244 1-216-073-00 RES,CHIP 10K 5% 1/10W
R245 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R248 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R250 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R251 1-216-049-91 RES,CHIP 1K 5% 1/10W
R252 1-247-815-91 CARBON 220 5% 1/4W
R253 1-216-073-00 RES,CHIP 10K 5% 1/10W
R254 1-249-389-11 CARBON 4.7 5% 1/4W
R257 8-719-041-97 DIODE MA113-(TX)
R265 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R266 1-216-073-00 RES,CHIP 10K 5% 1/10W
R301 1-216-073-00 RES,CHIP 10K 5% 1/10W
R302 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R303 1-216-025-91 RES,CHIP 100 5% 1/10W
R304 1-216-025-91 RES,CHIP 100 5% 1/10W
R305 1-216-033-00 RES,CHIP 220 5% 1/10W
R306 1-216-033-00 RES,CHIP 220 5% 1/10W
R307 1-216-033-00 RES,CHIP 220 5% 1/10W
