KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
Adjustment Item Table
Device Functionality Note Data Range Function Note for Register Slava RAM Address
Name No Name Different Data No. (bit) Address (bit)
GEO 0 HPS 1E/16 3F H Position 50/60HZ 12 (7-2) CXA2130S(88H) 82 (7-2)
1 HSZ 1F 3F H Size 50/60HZ 11 (7-2) 81 (7-2)
2 PAP 1F 3F Pin Amp 50/60HZ 13 (7-2) 83 (7-2)
3 TLT 7 0F Trapezium 50/60HZ 15 (7-4) 85 (7-4)
4 VPS 1F 3F V Position 50/60HZ 0F (7-2) 7F (7-2)
5 VSZ 1F 3F V Size 50/60HZ 0E (7-2) 7E (7-2)
6 SCO 7 0F S Correction 50/60HZ 10 (7-4) 80 (7-4)
7 VLN 7 0F V Linearity 50/60HZ 10 (3-0) 80 (3-0)
8 BOW 7 0F AFC Bow 50/60HZ 16 (7-4) 86 (7-4)
9 AGL 7 0F AFC-Angle 50/60HZ 16 (3-0) 86 (3-0)
10 UPN 1F 3F Upper Pin 50/60HZ 14 (7-2) 84 (7-2)
11 LPN 2F 3F Lower Pin 50/60HZ 18 (7-2) 88 (7-2)
12 HBL 1 1 H Blanking on/off 18 (1) 67 (1)
13 LBL 0F/0F 0F Left H Blanking 50/60HZ 17 (7-4) 87 (7-4)
14 RBL 00/00 0F Right H Blanking 50/60HZ 17 (3-0) 87 (3-0)
WHB 0 RDR 25/2A 3F R Drive DYNAMIC/others 09 (7-2) CXA2130S(88H) 8F (7-2)
1 GDR 2A 3F G Drive DYNAMIC/others 0A (7-2) 90 (7-2)
2 BDR 2A 3F B Drive DYNAMIC/others 0B (7-2) 91 (7-2)
3 RCT 07/07 0F R Cutoff SECAM/others 07 (3-0) 93 (3-0)
4 GCT 7 0F G Cutoff SECAM/others 08 (7-4) 94 (7-4)
5 BCT 7 0F B Cutoff SECAM/others 08 (3-0) 94 (3-0)
6 BMN 15 1F Brightness Minimum Data 97
7 SBR 28 3F Sub Brightness Control 98
SAJ 0 PMX 37 3F Picture Maximum Data CXA2130S(88H) 96
1 SHU 8 0F Sub Hue Control TV/Video 99
2 SSH 05/0A 0F Sub Sharpness Control TV/Video 9A
3 SCL 1F 3F Sub Color Control NTSC/others 9B
VP 0 EHT 07/07 0F EHT Comp 50/60HZ 15 (3-0) CXA2130S(88H) 85 (3-0)
1 GMA 2 03 Gamma Correction Refer NVM Map A4 0B (1-0) 1A3 (1-0)
2 YDL 08/09/08 0F Y Delay PAL/SECAM/NTSC 0C (3-0) 8C (3-0)
3 SST 1 03 SECAM ID Start Position 1B (1-0) 6A (1-0)
4 SSP 1 03 SECAM ID Stop Position 1B (3-2) 6A (3-2)
5 SLV 2 03 SECAM ID Level 1C (1-0) 6B (1-0)
6 SBF 22 3F SECAM BELL fO 1C (7-2) 6B (7-2)
7 DYC 1 1 Dynamic Color on/off 0A (1) 59 (1)
8 ABL 1 1 ABL Mode Switching STANDARD ALWAYS 0 09 (1) 58 (1)
9 VTH 1 1 ABL Detection Vth Switching 09 (0) 58 (0)
10 SFO 01/01 1 FO Switching for Sharpness NTSC/others 05 (1) 198 (1)
11 DCX 1 1 DC Trans. Ratio Switching 06 (1) 55 (1)
12 SHT 01/01 1 Pre-/Overshoot ratio Switch NTSC/others 06 (0) 199 (0)
