– 29 –
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
Adjustment Item Table
Device Functionality Note Data Range Function Note for Register Slava RAM Address
Name No Name Different Data No. (bit) Address (bit)
VP 13 HDW 0 1 H Drive Pulse Width Switch 00 (6) 4F (6)
14 AFC 01/00/01 03 AFC Gain Control TV/Video/Text 0F (1-0) 8D (1-0)
15 HOS 7 0F H Oscillation 0C (7-4) 5B (7-4)
16 HSS 0 1 Slice Level of H Sync Sep. 0D (1) 5C (1)
17 VSS 0 1 Slice Level of V Sync Sep. 0D (0) 5C (0)
18 HMS 01/01 1 Macro Vision C/m off/on 50/60Hz 0E (0) 7E (0)
19 YUV 1 1 YUV Switch Control 01 (0) 50 (0)
20 CDV 1 3 CD mode for Video Video only 0D (5-4) 1A1 (5-4)
21 RON 1 1 R ON not memorized 01 (3) 50 (3)
22 GON 1 1 G ON not memorized 01 (2) 50 (2)
23 BON 1 1 B ON not memorized 01 (1) 50 (1)
24 PON 1 1 P ON not memorized 00 (7) 4F (7)
25 BLK 0 1 BLK Off 12 (0) 61 (0)
26 VMC 0 1 VM Off 13 (0) 62 (0)
AP 0 INF 5 3F Input Attenuation When surround off 00 (5-0) TDA7429 19F (5-0)
1 INS 0A 3F Input Attenuation When surround on 1A0 (5-0)
2 PH1 03 3 Phase 1 Register Selection 02 76 (1-0)
3 PH2 0 3 Phase 2 Register Selection 76 (3-2)
4 PH3 0 3 Phase 3 Register Selection 76 (5-4)
5 PH4 0 3 Phase 4 Register Selection 76 (7-6)
6 BCS 0 3 Bass Center Shift #4 (3-0) 1A8 (1-0)
7 TCS 0 3 Treble Center Shift #5 (3-0) 1A9 (1-0)
8 TRF 2 3 RF Treble Offset #5 (3-0) 1A9 (5-4)
MSP 0 WST 15 FF W/G Stereo Threshold MSP3415D 157 (7-0)
1 WBT EA FF W/G Bilingual Threshold (84H) 158 (7-0)
2 WLL 5 FF W/G Monaural Threshold 159 (7-0)
3 WAC 0 0F W/G Agreement Count 15A (3-0)
4 WDL 30 FF W/G Search Delay 15B (7-0)
5 NDL 20 FF NICAM Search Delay 15C (7-0)
6 SDL 10 FF Stereo status Read Delay 15D (7-0)
7 AGC 1 1 AGC Switch Auto/Constant BB (7) 108 (7)
8 REL 28 3F AGC Gain at Constant Mode BB (6-1) 108 (6-1)
9 CRM 0 1 Carrier muting on/off BB (9) 107 (1)
10 ACO 1 1 Audio Clock out on/off 83 (5) 10C (5)
11 FP 1B 7F FM Prescale for non-M system 0E (7-0) 16C (6-0)
12 FPM 32 7F FM Prescale for M system 0E (7-0) 16D (6-0)
13 FH 36 7F FM Prescale for HDEV 0E (7-0) 16E (6-0)
14 FHM 65 7F FM Prescale for HDEV and M 0E (7-0) 16F (6-0)
15 WGP 2A 7F W/G Prescale 0E (7-0) 170 (6-0)
16 NIP 6D 7F NICAM Prescale 10 (7-0) 138 (6-0)
17 ERR 50 FF Auto FM switch Threshold 21 (10-3) 166 (7-0)
18 VOL 6D FF Loud Speaker gain 7000h to 7ffoh 0000 (15-4) 1A7 (7-0)
