– 30 –
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
Adjustment Item Table
Device Functionality Note Data Range Function Note for Register Slava RAM Address
Name No Name Different Data No. (bit) Address (bit)
TXT 0 TXH 1 3 Teletext Horizontal Position (58H) 18D (1-0)
1 TXV 0 3 Teletext Vertical Position 18D (6-4)
OPM 0 OSH 0A 3F OSD H Position Option-Misc. AC (7-2)
1 COM 0 03 Comb Selection A5 (7-6)
2 APC 1 1 APC Switch A4 (5)
3 TSY 0 03 TV Sys at Auto TV Sys A4 (4-3)
4 MUT 0 1 No Signal Mute A4 (0)
5 AFM 1 1 Auto FM switch A4 (1)
6 RFB 0 3 C-BPF Control A5 (5-4)
7 TV0 0 7 Tilt to V-Angle offset A5 (2-0)
8 DBL 0 1 Disable Blueback Function A4 (2)
OPB 0 OP1 ✽ FF Optional Bits 1 (see below) Option-Bits 45
1 OP2 1 FF Optional Bits 2 (see below) 46
2 OP3 0 FF Optional Bits 3 (see below) 47
NOTE
•
shaded items are fixed data.
• Standard data listed on the Adjustment Item Table are reference values, therefore it may be different for each model and for each mode.
• Note for Different Data Those are the standard data values written on the microprocessor. Therefore, the data values of the modes and stored respectively in the
memory.
In case of a device replacement, adjustment by rewriting the data value is necessary for some items.
