– 19 –
KV-PG21P40/PG21M70/PG21P70
RM-952
Adjustment Item Table
Device
Data
Range
Initial
Data
Note for Different Data
Function
Item Adj.
No. Item
40 TBR 00-0F 08 Set Teletext RGB Brightness SAA5264(58)
42 TCH 00-03 01 Twisted Character Set Configuration
43 BKP 00-3F 00 00 : Positive, 01 : Negative Picture Data at Blanking OFF
44 ODL 00-FF 10 Power ON Delay Other Control
45 OSH 00-3F 0A OSD H Position
46 TSH 00–03 00 00:B/G, 01:I, 02:D/K, 03:M TV System at Auto Preset
47 DKS 00–01 01 D/K Stereo enable/disable
48 MUT 00–01 00 Muting on/off at No Sync
49 ABL 00–01 00 Bright ABL Switch
4A SCM 00–01 00 SECAM Trap active/inactive
4B SLS 00–01 01 Active SL.OR.IFI Sync
4C SSV 00–07 02 Space Sound Volume Step Up
4D VPW 00–7F 28
Timer of Video Processor start up wait
4E OP1 00–FF 2F Optional Flags 0 (see page 20)
4F OP2 00–FF 0F Optional Flags 1 (see page 20)
50 OP3 00–FF 00 Optional Flags 2 (see page 20)
NOTE
• Standard data listed on the Adjustment Item Table are reference values, therefore it may be different for each model
and for each mode.
• Note for Different Data Those are the standard data values written on the microprocessor. Therefore, the data values
of the modes and stored respectively in the memory.
In case of a device replacement, adjustment by rewriting the data value is necessary for some items.
