– 48 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG21P40/PG21M70/PG21P70
RM-952
D500 8-719-911-19 1SS119-25
D501 8-719-911-19 1SS119-25
D502 8-719-302-43 EL1Z
D503 8-719-302-43 EL1Z
D504 8-719-302-43 EL1Z
D520 8-719-911-19 1SS119-25
(KV-PG21P40 (MALAYSIA/
SINGAPORE/PG21M70)
D520 8-719-988-61 1SS355TE-17 (KV-PG21P70)
D521 8-719-911-19 1SS119-25 (KV-PG21P40 (MALAYSIA/
SINGAPORE/PG21M70)
D521 8-719-988-61 1SS355TE-17 (KV-PG21P70)
D552 8-719-908-03 GP08D
D553 8-719-109-89 RD5.6ESB2
D600 8-719-030-33 DIODE EG01CV1
D601 8-719-077-77 D3SB60F3
D602 8-719-510-73 S3L20UF4 (EXCEPT KV-PG21P70)
D602 8-719-057-05 ERD28-08S (KV-PG21P70)
D603 8-719-110-39 RD15ES-B1
D604 8-719-063-70 D1NL20U
D605 8-719-063-70 D1NL20U
D606 8-719-063-70 D1NL20U
D608 8-719-312-10 RU4AM-T3
D609 8-719-067-18 RN4Z (KV-PG21P40(SINGAPORE)/
PG21P70(E)/PG21M70)
D609 8-719-510-73 S3L20UF4 (KV-PG21P40(MALAYSIA ONLY)
D800 8-719-911-19 1SS119-25
D802 8-719-908-03 GP08D
D803 8-719-908-03 GP08D
D804 8-719-081-00 DIODE BY228/A52A/
D805 8-719-069-60 UDZSTE-179.1B
D851 8-719-979-85 EGP20G
D853 8-719-988-61 1SS355TE-17
<CONNECTOR>
DY1 * 1-580-798-11 CONNECTOR PIN (DY) 6P
<FUSE>
F600 1-532-237-00 FUSE, TIME-LAG (BET) 3.15A/250V
<FERRITE BEAD>
FB001 1-410-397-21 FERRITE 1.1UH
FB100 1-239-358-21 FILTER, NOISE
FB602 1-410-397-21 FERRITE 1.1UH
FB603 1-412-911-31 FERRITE 0UH
FB800 1-410-397-21 FERRITE 1.1UH
<IC>
IC001 8-752-925-64 IC CXP85224A-079S
IC002 8-759-371-21 MM1319AFBE
IC003 8-759-672-78 M24C08-BN6(A)
IC004 8-742-225-20 IC SBX3081-21
IC203 6-700-036-01 IC AN5279
IC301 6-700-146-01 IC TDA8844/N2 (KV-PG21M70)
IC301 6-700-145-01 IC TDA8843/N2 (EXCEPT KV-PG21M70)
IC400 6-700-033-01 IC MM1501XNRE
IC402 8-759-100-96 UPC4558G2
IC520 8-759-356-16 NJM4556AD (KV-PG21P40(MALAYSIA)/
PG21M70)
IC520 8-759-603-37 M5216P (KV-PG21P40(SINGAPORE)/PG21P70)
IC551 8-759-835-98 IC AN5522
IC601 8-749-019-42 IC STR-F6707A
IC602 8-749-920-61 SE-135N
IC604 8-759-459-99 PQ09RD11
IC850 8-759-700-07 NJM2903M
IC851 8-759-100-96 UPC4558G2
<JACK>
J200 1-770-785-12 JACK
J400 1-779-849-11 JACK BLOCK, PIN 4P
J401 1-779-205-11 JACK, PIN 2P
<CHIP CONDUCTOR>
JR001 1-216-295-91 SHORT 0
JR003 1-216-295-91 SHORT 0
JR012 1-216-295-91 SHORT 0
JR013 1-216-295-91 SHORT 0
JR014 1-216-295-91 SHORT 0
JR015 1-216-295-91 SHORT 0
JR017 1-216-295-91 SHORT 0
JR018 1-216-295-91 SHORT 0
JR020 1-216-295-91 SHORT 0
JR030 1-216-295-91 SHORT 0
JR034 1-216-295-91 SHORT 0 (KV-PG21M70 0NLY)
JR035 1-216-295-91 SHORT 0
JR100 1-216-295-91 SHORT 0 (EXCEPT KV-PG21M70)
JR202 1-216-295-91 SHORT 0
JR300 1-216-295-91 SHORT 0 (EXCEPT KV-PG21M70)
JR301 1-216-295-91 SHORT 0 (KV-PG21M70 0NLY)
JR304 1-216-295-91 SHORT 0
<COIL>
L001 1-414-855-31 INDUCTOR 1UH
L002 1-414-184-41 INDUCTOR 15UH
L100 1-414-856-11 INDUCTOR 10UH
L101 1-410-498-11 INDUCTOR 1.2UH
L102 1-410-985-42 INDUCTOR 0.22UH
L103 1-410-987-42 INDUCTOR 0.33UH
L300 1-410-512-11 INDUCTOR 18UH (KV-PG21M70)
L300 1-410-511-11 INDUCTOR 15UH
(EXCEPT KV-PG21M70)
L301 1-410-510-11 INDUCTOR 12UH
(KV-PG21M70 0NLY)
L302 1-410-508-11 INDUCTOR 8.2UH
(KV-PG21M70 0NLY)
L303 1-410-508-11 INDUCTOR 8.2UH
(KV-PG21M70 0NLY)
L304 1-410-510-11 INDUCTOR 12UH
(KV-PG21M70 0NLY)
L305 1-410-510-11 INDUCTOR 12UH
L306 1-410-500-11 INDUCTOR 1.8UH
(KV-PG21M70 0NLY)
L307 1-410-501-11 INDUCTOR 2.2UH
(KV-PG21M70 0NLY)
L308 1-410-501-11 INDUCTOR 2.2UH
L309 1-410-502-11 INDUCTOR 2.7UH
(KV-PG21M70 0NLY)
L310 1-408-608-31 INDUCTOR 27UH
(KV-PG21M70 0NLY)
