– 49 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG21P40/PG21M70/PG21P70
RM-952
L400 1-414-855-31 INDUCTOR 1UH
L500 1-408-947-00 INDUCTOR 2.2MH
L600 1-412-533-21 INDUCTOR 47UH
L800 1-406-677-11 INDUCTOR 10MH
L802 1-424-796-11 COIL, HORIZONTAL LINEARITY
L803 1-414-493-41 INDUCTOR 4.7MH
<PHOTO COUPLER>
PH600 ! 8-749-010-64 PC123F2
<TRANSISTOR>
Q001 8-729-421-19 UN2213
Q002 8-729-421-19 UN2213
Q003 8-729-010-25 MSD601-RT1
Q004 8-729-010-25 MSD601-RT1
Q005 8-729-010-25 MSD601-RT1
Q100 8-729-010-25 MSD601-RT1
Q102 8-729-022-54 TRANSISTOR 2SC3779C,D-AA
Q103 8-729-424-67 UN2216 (KV-PG21M70 0NLY)
Q104 8-729-424-67 UN2216 (KV-PG21M70 0NLY)
Q105 8-729-010-25 MSD601-RT1
Q106 8-729-010-25 MSD601-RT1
Q201 8-729-010-25 MSD601-RT1
Q204 8-729-216-22 2SA1162-G
Q205 8-729-421-22 UN2211
Q300 8-729-010-05 MSB709-RT1 (KV-PG21M70 0NLY)
Q301 8-729-010-05 MSB709-RT1
Q302 8-729-010-05 MSB709-RT1 (KV-PG21M70 0NLY)
Q303 8-729-010-25 MSD601-RT1
Q304 8-729-010-05 MSB709-RT1 (KV-PG21M70 0NLY)
Q305 8-729-010-05 MSB709-RT1
Q306 8-729-010-25 MSD601-RT1 (KV-PG21M70 0NLY)
Q307 8-729-010-25 MSD601-RT1 (KV-PG21M70 0NLY)
Q308 8-729-424-67 UN2216 (KV-PG21M70 0NLY)
Q309 8-729-010-25 MSD601-RT1
Q310 8-729-424-67 UN2216 (KV-PG21M70 0NLY)
Q311 8-729-010-25 MSD601-RT1 (KV-PG21M70 0NLY)
Q313 8-729-424-67 UN2216 (KV-PG21M70 ONLY)
Q314 8-729-421-22 UN2211 (KV-PG21M70 ONLY)
Q315 8-729-010-25 MSD601-RT1
Q318 8-729-010-25 MSD601-RT1
Q320 8-729-421-22 UN2211
Q321 8-729-424-67 UN2216 (KV-PG21M70 ONLY)
Q400 8-729-010-05 MSB709-RT1
Q401 8-729-424-67 UN2216
Q402 8-729-424-67 UN2216
Q403 8-729-010-05 MSB709-RT1
Q404 8-729-010-05 MSB709-RT1
Q405 8-729-010-05 MSB709-RT1
Q406 8-729-010-25 MSD601-RT1
Q407 8-729-010-25 MSD601-RT1
Q500 8-729-200-17 2SA1091-O
Q520 8-729-423-33 2SC3311A-QRSTA (EXCEPT KV-PG21P70)
Q800 8-729-140-50 2SC3209LK
Q801 8-729-055-74 TRANSISTOR 2SD2624-CA
Q802 8-729-050-48 TRANSISTOR IRF614-005
Q850 8-729-010-25 MSD601-RT1
Q851 8-729-010-05 MSB709-RT1
<RESISTOR>
R001 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R002 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R003 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R004 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R005 1-216-043-91 RES-CHIP 560 5% 1/10W
R006 1-216-043-91 RES-CHIP 560 5% 1/10W
R007 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R008 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R009 1-216-037-00 RES-CHIP 330 5% 1/10W
R010 1-216-037-00 RES-CHIP 330 5% 1/10W
R011 1-216-295-91 SHORT 0
R012 1-216-049-11 RES-CHIP 1K 5% 1/10W
R013 1-216-041-00 RES-CHIP 470 5% 1/10W
R014 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R015 1-216-025-11 RES-CHIP 100 5% 1/10W
R016 1-216-037-00 RES-CHIP 330 5% 1/10W
R017 1-216-049-11 RES-CHIP 1K 5% 1/10W
R018 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R019 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R020 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R021 1-216-049-11 RES-CHIP 1K 5% 1/10W
(KV-PG21M70)
R022 1-216-049-11 RES-CHIP 1K 5% 1/10W
R024 1-216-025-11 RES-CHIP 100 5% 1/10W
R025 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R026 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R027 1-216-101-00 RES-CHIP 150K 5% 1/10W
R028 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R029 1-216-025-11 RES-CHIP 100 5% 1/10W
R031 1-216-025-11 RES-CHIP 100 5% 1/10W
R032 1-216-049-11 RES-CHIP 1K 5% 1/10W
R033 1-216-073-91 RES-CHIP 10K 5% 1/10W
R034 1-216-073-91 RES-CHIP 10K 5% 1/10W
R035 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R036 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R037 1-216-049-11 RES-CHIP 1K 5% 1/10W
R038 1-216-049-11 RES-CHIP 1K 5% 1/10W
R039 1-216-043-91 RES-CHIP 560 5% 1/10W
R042 1-216-039-00 RES-CHIP 390 5% 1/10W
R043 1-216-025-11 RES-CHIP 100 5% 1/10W
R044 1-216-033-00 RES-CHIP 220 5% 1/10W
R045 1-216-073-91 RES-CHIP 10K 5% 1/10W
R046 1-208-816-11 METAL CHIP 27K 0.5% 1/10W
R047 1-216-025-11 RES-CHIP 100 5% 1/10W
R048 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R049 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R050 1-208-820-11 METAL CHIP 39K 0.5% 1/10W
R051 1-216-073-91 RES-CHIP 10K 5% 1/10W
R052 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R053 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R054 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R055 1-216-049-11 RES-CHIP 1K 5% 1/10W
R056 1-216-049-11 RES-CHIP 1K 5% 1/10W
R057 1-216-025-11 RES-CHIP 100 5% 1/10W
R058 1-216-025-11 RES-CHIP 100 5% 1/10W
R059 1-216-033-00 RES-CHIP 220 5% 1/10W
R060 1-216-033-00 RES-CHIP 220 5% 1/10W
R061 1-216-033-00 RES-CHIP 220 5% 1/10W
R062 1-216-049-11 RES-CHIP 1K 5% 1/10W
(KV-PG21M70)
A
To Next Page
