– 50 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG21P40/PG21M70/PG21P70
RM-952
R306 1-216-039-00 RES-CHIP 390 5% 1/10W
R307 1-216-033-00 RES-CHIP 220 5% 1/10W
R308 1-216-027-00 RES-CHIP 120 5% 1/10W
(KV-PG21M70)
R309 1-216-029-00 RES-CHIP 150 5% 1/10W
(KV-PG21M70)
R310 1-216-039-00 RES-CHIP 390 5% 1/10W
R311 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R312 1-216-033-00 RES-CHIP 220 5% 1/10W
R313 1-216-037-00 RES-CHIP 330 5% 1/10W
(KV-PG21M70)
R314 1-216-037-00 RES-CHIP 330 5% 1/10W
R315 1-216-081-00 RES-CHIP 22K 5% 1/10W
(KV-PG21M70)
R316 1-216-031-00 RES-CHIP 180 5% 1/10W
R317 1-216-041-00 RES-CHIP 470 5% 1/10W
(KV-PG21M70)
R318 1-216-081-00 RES-CHIP 22K 5% 1/10W
(KV-PG21M70)
R319 1-216-041-00 RES-CHIP 470 5% 1/10W
(KV-PG21M70)
R320 1-216-081-00 RES-CHIP 22K 5% 1/10W
R323 1-216-041-00 RES-CHIP 470 5% 1/10W
R324 1-216-041-00 RES-CHIP 470 5% 1/10W
(KV-PG21M70)
R325 1-216-081-00 RES-CHIP 22K 5% 1/10W
(KV-PG21M70)
R326 1-216-081-00 RES-CHIP 22K 5% 1/10W
(KV-PG21M70)
R327 1-216-049-11 RES-CHIP 1K 5% 1/10W
R328 1-216-025-11 RES-CHIP 100 5% 1/10W
R329 1-216-043-91 RES-CHIP 560 5% 1/10W
R330 1-216-295-91 SHORT 0
R331 1-216-295-91 SHORT 0
R332 1-216-295-91 SHORT 0
R333 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R334 1-216-025-11 RES-CHIP 100 5% 1/10W
R335 1-216-025-11 RES-CHIP 100 5% 1/10W
R336 1-216-025-11 RES-CHIP 100 5% 1/10W
R337 1-216-073-91 RES-CHIP 10K 5% 1/10W
R338 1-216-077-91 RES-CHIP 15K 5% 1/10W
R339 1-216-035-00 RES-CHIP 270 5% 1/10W
R340 1-162-974-11 CERAMIC CHIP 0.01UF 50V
R342 1-216-295-91 SHORT 0
R345 1-216-025-11 RES-CHIP 100 5% 1/10W
R348 1-216-025-11 RES-CHIP 100 5% 1/10W
R350 1-216-039-00 RES-CHIP 390 5% 1/10W
R352 1-216-073-91 RES-CHIP 10K 5% 1/10W
R353 1-216-119-00 RES-CHIP 820K 5% 1/10W
R354 1-216-119-00 RES-CHIP 820K 5% 1/10W
R355 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R356 1-216-049-11 RES-CHIP 1K 5% 1/10W
R357 1-216-101-00 RES-CHIP 150K 5% 1/10W
R358 1-216-025-11 RES-CHIP 100 5% 1/10W
R360 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R361 1-216-033-00 RES-CHIP 220 5% 1/10W
R362 1-216-083-00 RES-CHIP 27K 5% 1/10W
R363 1-216-295-91 SHORT 0
R364 1-216-077-91 RES-CHIP 15K 5% 1/10W
R365 1-216-295-91 SHORT 0
R367 1-216-099-00 RES-CHIP 120K 5% 1/10W
R368 1-216-049-11 RES-CHIP 1K 5% 1/10W
R063 1-216-049-11 RES-CHIP 1K 5% 1/10W
(KV-PG21M70)
R064 1-216-049-11 RES-CHIP 1K 5% 1/10W
(KV-PG21M70)
R066 1-216-049-11 RES-CHIP 1K 5% 1/10W
R069 1-216-049-11 RES-CHIP 1K 5% 1/10W
(EXCEPT KV-PG21M70)
R070 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(EXCEPT KV-PG21M70)
R072 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R073 1-216-081-00 RES-CHIP 22K 5% 1/10W
R074 1-216-049-11 RES-CHIP 1K 5% 1/10W
R076 1-216-025-11 RES-CHIP 100 5% 1/10W
R077 1-216-025-11 RES-CHIP 100 5% 1/10W
R100 1-216-049-11 RES-CHIP 1K 5% 1/10W
R103 1-211-981-11 METAL CHIP 33 0.5% 1/16W
R106 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R107 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R108 1-216-041-00 RES-CHIP 470 5% 1/10W
R109 1-216-019-00 RES-CHIP 56 5% 1/10W
R111 1-216-073-91 RES-CHIP 10K 5% 1/10W
(KV-PG21M70)
R113 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(KV-PG21M70)
R114 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(KV-PG21M70)
R115 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R117 1-216-081-00 RES-CHIP 22K 5% 1/10W
R118 1-216-041-00 RES-CHIP 470 5% 1/10W
R119 1-216-081-00 RES-CHIP 22K 5% 1/10W
R120 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R121 1-216-081-00 RES-CHIP 22K 5% 1/10W
R122 1-216-109-00 RES-CHIP 330K 5% 1/10W
R123 1-216-081-00 RES-CHIP 22K 5% 1/10W
R124 1-216-081-00 RES-CHIP 22K 5% 1/10W
R125 1-215-925-11 METAL OXIDE 22K 5% 3W
R128 1-216-025-11 RES-CHIP 100 5% 1/10W
R129 1-211-977-11 METAL CHIP 22 0.5% 1/16W
R130 1-216-049-11 RES-CHIP 1K 5% 1/10W
R133 1-249-389-11 CARBON 4.7 5% 1/4W
R200 1-216-073-91 RES-CHIP 10K 5% 1/10W
R201 1-216-295-91 SHORT 0
R206 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R209 1-216-073-91 RES-CHIP 10K 5% 1/10W
R211 1-249-409-11 CARBON 220 5% 1/4W
R212 1-216-049-11 RES-CHIP 1K 5% 1/10W
R214 1-216-295-91 SHORT 0
R221 1-216-025-11 RES-CHIP 100 5% 1/10W
R222 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R240 1-216-077-91 RES-CHIP 15K 5% 1/10W
R241 1-216-077-91 RES-CHIP 15K 5% 1/10W
R242 1-216-073-91 RES-CHIP 10K 5% 1/10W
R243 1-216-073-91 RES-CHIP 10K 5% 1/10W
R300 1-216-033-00 RES-CHIP 220 5% 1/10W
R301 1-216-033-00 RES-CHIP 220 5% 1/10W
(KV-PG21M70)
R302 1-216-033-00 RES-CHIP 220 5% 1/10W
R303 1-216-033-00 RES-CHIP 220 5% 1/10W
(KV-PG21M70)
R304 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R305 1-216-045-00 RES-CHIP 680 5% 1/10W
(KV-PG21M70)
