– 34 –
KV-PG21P40/PG21M70/PG21P70
RM-952
KV-PG21P40 (Malaysia) PG21P40 (Singapura) PG21M70 PG21P70
C300 56P :CHIP 56P :CHIP 47P :CHIP 56P :CHIP
C302 # # 47P :CHIP #
C303 # # 68P :CHIP #
C308 # # 390P :CHIP #
C309 # # 330P :CHIP #
C311 # # 470P :CHIP #
C316 # # 47P :CHIP #
C370 # # 0 :CHIP #
CF345 # # BAND PASS (F4.5C) #
CF360 # # BAND PASS (F6.0C) #
CF365 # # BAND PASS (F6.5C) #
CN601 2P 3P 3P 3P
CT345 # # TRAP CERAMIC (T4.5C) #
CT360 # # TRAP CERAMIC (T60B) #
CT365 # # TRAP CERAMIC (T65B) #
D100 # # MA77 #
D301 # # 1SS355TE-17 #
D326 1SS355TE-17 1SS355TE-17 # #
D520 1SS119-25TD 1SS119-25TD 1SS119-25TD 1SS35-5TE-17
D521 1SS119-25TD 1SS119-25TD 1SS119TD 1SS35-5TE-17
D602 S3L20UF4 S3L20UF4 S3L20UF4 ERD28-08S
D609 S3L20UF4 RN4Z RN4Z RN4Z
IC301 TDA8843/N2 TDA8843/N2 TDA8844/N2 TDA8843/N2
IC520 NJM4556AD M5216P NJM4556AD M5216P
JR034 # # 0 :CHIP #
JR100 0 :CHIP 0 :CHIP # 0 :CHIP
JR300 0 :CHIP 0 :CHIP # 0 :CHIP
JR301 # # 0 :CHIP #
L300 15UH 15UH 18UH 15UH
L301 # # 12UH #
L302 # # 8.2UH #
L303 # # 8.2UH #
L304 # # 12UH #
L306 # # 1.8UH #
L307 # # 2.2UH #
L309 # # 2.7UH #
L310 # # 27UH #
Q103 # # UN2216 #
Q104 # # UN2216 #
Q300 # # MSB709-RT1 #
Q302 # # MSB709-RT1 #
Q304 # # MSB709-RT1 #
Q306 # # MSD601-RT1 #
Q307 # # MSD601-RT1 #
Q308 # # UN2216 #
Q310 # # UN2216 #
Q311 # # MSD601-RT1 #
Q313 # # UN2216 #
Q314 # # UN2211 #
Q321 # # UN2216 #
Q520 2SC3311A-QRSTA 2SC3311A-QRSTA 2SC3311A-QRSTA MSD601-RT1
R021 # # 1.0K :CHIP #
R062 # # 1.0K :CHIP #
R063 # # 1.0K :CHIP #
R064 # # 1.0K :CHIP #
R069 1.0K :CHIP 1.0K :CHIP # 1.0K :CHIP
R070 4.7K :CHIP 4.7K :CHIP # 4.7K :CHIP
R076 100 :CHIP 100 :CHIP 100 :CHIP #
R111 # # 10K :CHIP #
R112 # # 6.8K :CHIP #
R113 # # 2.2K :CHIP #
R114 # # 2.2K :CHIP #
R202 22K :CHIP # # #
R209 10K :CHIP 10K :CHIP 10K :CHIP #
R301 # # 220 :CHIP #
R303 # # 220 :CHIP #
R305 # # 680 :CHIP #
R308 # # 120 :CHIP #
R309 # # 150 :CHIP #
R313 # # 330 :CHIP #
R315 # # 22K :CHIP #
R317 # # 470 :CHIP #
R318 # # 22K :CHIP #
R319 # # 470 :CHIP #
R324 # # 470 :CHIP #
R325 # # 22K :CHIP #
R326 # # 22K :CHIP #
R522 10K :CHIP 10K :CHIP 22K :CHIP 10K :CHIP
R602 1 :10W 0.68 :10W 0.68 :10W 0.68 :10W
R603 1 :10W 0.68 :10W 0.68 :10W 0.68 :10W
R627 1 :10W 0.68 :10W 0.68 :10W 0.68 :10W
A Board ✼ Mark List
Note: The parts indicated as "#" in this circuit diagram are not listed here, as they are not used for these models.
