– 46 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG21P40/PG21M70/PG21P70
RM-952
C206 1-126-968-11 ELECT 100UF 20.00% 50V
C209 1-126-942-61 ELECT 1000UF 20.00% 25V
C210 1-128-551-11 ELECT 22UF 20.00% 25V
C211 1-126-964-11 ELECT 10UF 20.00% 50V
C212 1-126-942-61 ELECT 1000UF 20.00% 25V
C213 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C242 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C300 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
(KV-PG21M70)
C300 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
(EXCEPT KV-PG21M70)
C301 1-162-920-11 CERAMIC CHIP 27PF 5.00% 50V
C302 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
(KV-PG21M70 ONLY)
C303 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
(KV-PG21M70 ONLY)
C304 1-119-662-91 CERAMIC CHIP 150PF 1.00% 50V
C305 1-126-933-11 ELECT 100UF 20.00% 16V
C306 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C307 1-126-957-11 ELECT 0.22UF 20.00% 50V
C308 1-163-131-00 CERAMIC CHIP 390PF 5.00% 50V
(KV-PG21M70 ONLY)
C309 1-163-263-11 CERAMIC CHIP 330PF 5.00% 50V
(KV-PG21M70 ONLY)
C310 1-163-131-00 CERAMIC CHIP 390PF 5.00% 50V
C311 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
(KV-PG21M70 ONLY)
C312 1-162-916-11 CERAMIC CHIP 12PF 5.00% 50V
C315 1-126-961-11 ELECT 2.2UF 20.00% 50V
C316 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
(KV-PG21M70 ONLY)
C317 1-216-295-91 SHORT 0
C318 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C319 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C320 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C321 1-126-963-11 ELECT 4.7UF 20.00% 50V
C323 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C327 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C328 1-164-222-91 CERAMIC CHIP 0.22UF 25V
C329 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C330 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C332 1-126-933-11 ELECT 100UF 20.00% 16V
C335 1-126-947-11 ELECT 47UF 20.00% 16V
C337 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C339 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C341 1-113-619-11 CERAMIC CHIP 0.47UF 10V
C342 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C343 1-162-917-11 CERAMIC CHIP 15PF 5.00% 50V
C344 1-162-917-11 CERAMIC CHIP 15PF 5.00% 50V
C345 1-162-967-11 CERAMIC CHIP 0.0033UF 10.00% 50V
C346 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C347 1-126-933-11 ELECT 100UF 20.00% 16V
C348 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C349 1-164-346-11 CERAMIC CHIP 1UF 16V
C352 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C353 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C354 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C355 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C356 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C357 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C358 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C359 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C360 1-130-495-00 MYLAR 0.1UF 5.00% 50V
C361 1-135-834-91 CERAMIC CHIP 2.2E+06PF 6.3V
C362 1-113-619-11 CERAMIC CHIP 0.47UF 10V
C363 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C364 1-126-964-11 ELECT 10UF 20.00% 50V
C366 1-126-933-11 ELECT 100UF 20.00% 16V
C368 8-719-110-37 RD13ES-B3
C370 1-216-295-91 SHORT 0 (KV-PG21M70 ONLY)
C400 1-126-934-11 ELECT 220UF 20.00% 16V
C405 1-126-960-11 ELECT 1UF 20.00% 50V
C406 1-115-156-11 CERAMIC CHIP 1UF 10V
C407 1-126-934-11 ELECT 220UF 20.00% 16V
C409 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C410 1-126-933-11 ELECT 100UF 20.00% 16V
C412 1-128-551-11 ELECT 22UF 20.00% 25V
C414 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C418 1-126-933-11 ELECT 100UF 20.00% 16V
C419 1-126-964-11 ELECT 10UF 20.00% 50V
C421 1-126-964-11 ELECT 10UF 20.00% 50V
C422 1-126-964-11 ELECT 10UF 20.00% 50V
C425 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C430 1-126-964-11 ELECT 10UF 20.00% 50V
C435 1-126-934-11 ELECT 220UF 20.00% 16V
C500 1-126-933-11 ELECT 100UF 20.00% 16V
C501 1-104-666-11 ELECT 220UF 20.00% 25V
C502 1-104-666-11 ELECT 220UF 20.00% 25V
C503 1-162-318-11 CERAMIC 0.001UF 10.00% 500V
C504 1-162-318-11 CERAMIC 0.001UF 10.00% 500V
C505 1-123-024-21 ELECT 33UF 160V
C507 1-102-228-00 CERAMIC 470PF 10.00% 500V
C508 1-107-654-11 ELECT 33UF 20.00% 250V
C509 1-106-379-12 MYLAR 0.033UF 10.00% 200V
C510 1-137-150-11 MYLAR 0.01UF 10.00% 100V
C520 1-126-964-11 ELECT 10UF 20.00% 50V
C521 1-126-964-11 ELECT 10UF 20.00% 50V
C552 1-137-194-81 FILM 0.47UF 5.00% 50V
C554 1-163-035-00 CERAMIC CHIP 0.047UF 50V
C555 1-126-949-11 ELECT 220UF 20.00% 35V
C556 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C557 1-126-948-11 ELECT 100UF 20.00% 35V
C558 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C559 1-106-220-00 MYLAR 0.1UF 10.00% 100V
C561 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C562 1-106-220-00 MYLAR 0.1UF 10.00% 100V
C600 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C601 ! 1-115-165-11 FILM 0.1UF 20.00% 275V
C602 1-117-752-11 ELECT(BLOCK) 330UF 20.00% 450V
C603 1-117-623-11 FILM 1500PF 3.00% 1.2KV
C604 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C605 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C606 1-104-666-11 ELECT 220UF 20.00% 25V
C607 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C608 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C609 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C610 1-126-948-11 ELECT 100UF 20.00% 35V
C611 1-163-145-00 CERAMIC CHIP 0.0015UF 5.00% 50V
C612 ! 1-119-886-51 CERAMIC 470PF 10.00% 250V
C614 1-123-024-21 ELECT 33UF 160V
C615 1-102-228-00 CERAMIC 470PF 10.00% 500V
C616 1-126-943-11 ELECT 2200UF 20.00% 25V
A
To Next Page
