Overview of Controls
Overview of Controls
Sony KV-SA32M36 Group F12 (GB)_2-348-392-11 (1)
Overview of Controls
4
L(MONO) R
PROG
MENU
(AUTO PROG)
SOUND
MODE
AUTO PROG:Press [MENU] for 5sec
3
2
0
9
PROG
MENU
(AUTO PROG)
SOUND
MODE
4
58
7
6
AUTO PROG:Press [MENU] for 5sec
1
qa
123
RLY
C
B
CR
qf
qd
qs
qg
4
L(MONO) R
120W MAX 8
c –
TV front panel
TV rear panel
x TV front and rear panels
Button/Terminal Function Page
1 ! Turn off or turn on the TV. 6
2 1 Standby indicator. 6
2 Wake Up indicator. 11
3 Remote control sensor. –
4 PROG +/– Select program number. –
5 2 +/– Adjust volume. –
6 t Select TV or video input. 33
Menu operations
5 2 +/– Select and adjust items. –
6 t Confirm selected items. –
7 MENU Display or cancel the menu. –
7 (AUTO PROG) Preset channels automatically. 8
8 SOUND MODE Select sound mode options. 12
5-Band Graphic Equalizer display will appear.
9 t4 Video input terminal 4. 33
0 i Headphone jack. –
qa Component video input terminal. 34
qs T Monitor output terminal. 33
qd t1, t2, t3 Video input terminal 1, 2, 3. 33
qf 8 Antenna input terminal. 33
qg Center speaker input terminal. 35
