Sony Trinitron PVM-1453MD - M Board

PVM-1353MD/1453MD
-M BOARD-
Note:
•
'Bl-113 : Pattern from the side which enables seeing.
: Pattern of the rear.
NOTE:
The circuit indicated as left contains high voltage of over
600 Vp-p. Care must
be paid to prevent an electric shock in
inspection or repairing.
-92-
