PVM-8041Q/8044Q
Power requirements 120V AC, 50/60 Hz
12V DC, with the Sony NP-1 A/1 B
battery pack (not supplied) or
AC-500 AC power adaptor
(not supplied)
Operating temperature range
0 - 35 °C
Storage temperature range
-10-+40 °C
Humidity 0 - 90%
Dimensions Approx. 217 x 217 x 352.5 mm (w/h/d)
(8 5 /e x 8 5 /8 x 14 inches)
not incl. projecting parts and controls
Weight Approx. 7.8 kg (17 lb 3 oz)
not incl. battery packs
Accessory supplied AC power cord (1)
Design and specifications are subject to change without
notice.
Y/C IN connector (4-pin mini DIN)
Pin No.
Signal
Description
1
Y-input
1 Vp-p, sync negative,
75 ohms
2
CHROMA sub-carrier-
input
300 mVp-p, burst
Delay time between Y
and C: within 0±100 nsec.,
75 ohms
3
GND for Y-input
GND
4
GND for CHROMA-
input
GND
TALLY/REMOTE connector (8-pin mini DIN)
Pin No.
Signal
1 Blue only
2 H/V delay
3
GND
4 INT/EXT SYNC
5
Tally
6
Underscan/normal scan
7
A/B or RGB/component
8
RGB/LINE
For remote control, connect the pin of the desired function to
pin 3 (GND).
— 2 —
