– 6 –
Mechanism deck
3
Two Screws (+BV TP 2.6 x 8)
4
1
Press
§
button
2
3
Two Screws (+BV TP 2.6 x 8
)
Front panel assy
Casstte lid assy
3-3. MECHANISM DECK REMOVAL
