3. Camera Operations: Monitoring Menu
79
Monitoring > VF Function
Makes settings related to viewfinder functions.
Menu item Setting Description
Zebra2 Level
0% to 109% (61%) Sets the display level of zebra 2.
Monitoring > Overlays/Frame Line
Makes settings related to information and frame lines superimposed on each output signal.
On/Off setting is selected using a checkbox (excluding Frame Line on Playback).
On: Checkbox selected
Off: Checkbox cleared
Menu item Setting Description
VF
Overlay (On/Off,
Info. A/Info. B/Rec Ind.)
Selects the information to display
superimposed on the viewfinder/monitor
screen output image.
Frame Line (On/Off,
Line A/Line B)
Selects the frame lines to display
superimposed on the viewfinder/monitor
screen output image.
SDI 1/2
Overlay (On/Off,
Info. A/Info. B/Rec Ind.)
Selects the information to display
superimposed on the SDI 1/2 output signal.
Frame Line (On/Off,
Line A/Line B)
Selects the frame lines to display
superimposed on the SDI 1/2 output signal.
SDI 3/4
Overlay (On/Off,
Info. A/Info. B/Rec Ind.)
Selects the information to display
superimposed on the SDI 3/4 output signal.
Frame Line (On/Off,
Line A/Line B)
Selects the frame lines to display
superimposed on the SDI 3/4 output signal.
Same as Monitor Selects whether the information displayed
superimposed on the SDI 3/4 output signal is
the same as for the Monitor output.
Monitor
Overlay (On/Off,
Info. A/Info. B/Rec Ind.)
Selects the information to display
superimposed on the Monitor output signal.
Frame Line (On/Off,
Line A/Line B)
Selects the frame lines to display
superimposed on the Monitor output signal.
HDMI
Overlay (On/Off,
Info. A/Info. B/Rec Ind.)
Selects the information to display
superimposed on the HDMI output signal.
Frame Line (On/Off,
Line A/Line B)
Selects the frame lines to display
superimposed on the HDMI output signal.
Same as SDI 1/2/3/4 / Same
as SDI 1/2 / Same as Monitor
Selects whether the information displayed
superimposed on the HDMI output signal is
the same as for the corresponding output.
Monitoring > Overlays/Frame Line
Makes settings related to information and frame lines superimposed on each output signal.
On/Off setting is selected using a checkbox (excluding Frame Line on Playback).
On: Checkbox selected
Off: Checkbox cleared
Menu item Setting Description
Overlay A/B Setup
Project
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the project
information in the output information set for
Overlay A and Overlay B.
Camera ID Status
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the camera ID
information in the output information set for
Overlay A and Overlay B.
TC/Genlock Status
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the timecode
external lock status and genlock status
information in the output information set for
Overlay A and Overlay B.
Timecode
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the timecode
information in the output information set for
Overlay A and Overlay B.
Audio Level Meter
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display an audio level
meter in the output information set for
Overlay A and Overlay B.
Look Status
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the type of
selected Look in the output information set
for Overlay A and Overlay B.
Output LUT
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the output LUT
information in the output information set for
Overlay A and Overlay B.
Rec Format/LUT
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the recording
format and recording LUT information in the
output information set for Overlay A and
Overlay B.
VF Status
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the viewfinder
status information in the output information
set for Overlay A and Overlay B.
Roll/Tilt Value
Info. A (On/Off)
Info. B (On/Off)
Selects whether to display the spirit level
information numerically in the output
information set for Overlay A and Overlay B.
[Note]
Roll/Tilt Value is grayed out and cannot be operated
when a CBK-3610XS is connected to the unit.
