Note
When installing to the floor, securely attach the air filter to the air filter cover, taking care not to hit the hook of the air filter cover. If
the air filter is attached to the air filter cover incorrectly, malfunction may occur.
When installing to the ceiling, securely attach the dust cover assembly to the unit. Incorrect attachment of the dust cover
assembly may cause a malfunction.
5-014-280-13(1)
Copyright 2020 Sony Corporation
11

Sony VPL-CWZ10 Specifications

General

Matrix size	0.64 \
Heat dissipation	1167 BTU/h
Native aspect ratio	16:10
Projection distance	- m
Vertical scan range	48 - 92 Hz
Horizontal scan range	15 - 92 kHz
Projection technology	3LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Focus	Manual
Throw ratio	1.29:1 - 2.07:1
Zoom capability	Yes
Focal length range	- mm
Light source type	Laser
Service life of light source	1000 h
RMS rated power	16 W
Supported video modes	480p, 576i, 720p, 1080i, 1080p
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
DVI port	No
Composite video in	0
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	36 dB
Noise level (economic mode)	28 dB
Ethernet LAN data rates	10, 100 Mbit/s
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85286200
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	342 W
Power consumption (standby)	0.5 W
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White

Weight and Dimensions

Depth	319.3 mm
Width	371 mm
Height	100 mm
Weight	5700 g
