41
Specifications
Others
INPUT OUTPUT
(Computer/video)
INPUT A RGB/YPBPR input connector: Mini D-sub 15 pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: TTL level high
impedance, positive/negative
Audio input connector: Stereo mini jack, rated input
500 mVrms, input impedance more than 47 kohms
INPUT B RGB input connector: Mini D-sub 15-pin female,
RGB: 0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync signal:
TTL level high impedance, positive/negative
Audio input connector: Stereo mini jack, rated input
500 mVrms, input impedance more than 47 kohms
INPUT C HDMI input connector: HDMI 19-pin, HDCP support,
Audio input connector: HDMI Audio support
INPUT D HDMI input connector: HDMI 19-pin, HDCP support,
Audio input connector: HDMI Audio support
VIDEO IN Video input connector: Phono jack, 1 Vp-p ± 2 dB,
sync negative, 75 ohmes terminated
Audio input connector: Stereo mini jack, rated input
500 mVrms, input impedance more than 47 kohms
OUTPUT MONITOR output connector: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: HD, VD 4 V (open),
1 Vp-p (75 ohms), positive/negative
Audio output connector: Stereo mini jack, stereo,
1 Vrms (maximum volume, when inputting 500 mVrms),
output impedance 5 kohms
Others connector RS-232C connector: D-Sub 9 pin male
LAN connector: RJ45, 10BASE-T/100BASE-TX
Operating
temperature/
Operating
humidity
0 °C to 40 °C (32 °F to 104 °F)/20% to 80% (no
condensation)
Storage
temperature/
Storage humidity
–10 °C to +60 °C (14 °F to 140 °F)/20% to 80% (no
condensation)
Power
requirements
VPL-CX236/CW256: 100 V to 240 V AC, 3.5 A-1.5 A,
50/60 Hz
VPL-CX276/CW276: 100 V to 240 V AC, 4.0 A-1.7 A,
50/60 Hz
Item Description
Model VPL-CX236/CX276/CW256/CW276
