31
Screen Menu
You can set the picture size, aspect mode, etc.
These items may not be available, depending on the type of input signal. For details, see “Input
Signals and Adjustable/Setting Items” (page 58).
Item names in brackets represent those printed on the remote control.
Note
Setting items Description
Picture Position
[POSITION]
You can store up to five combinations of lens settings, aspect ratio, and
blanking.
After setting the lens, aspect, and blanking, select from “1.85:1,”
“2.35:1,” “Custom 1,” “Custom 2,” or “Custom 3” depending on the
subtended screen angle, and after confirming, continue by selecting
“Save,” “Delete,” or “Select.”
Save: Stores the current lens settings (focus, window size, window
position) in the selected position. If a setting is already stored in that
position, it is overwritten.
Delete: Deletes the stored setting. After the setting is deleted, “1.85:1,”
“2.35:1,” “Custom 1,” “Custom 2,” or “Custom 3” in the display change
to “---.”
Select: Recalls the settings of the selected position.
Tips
• The optimal aspect ratio is preset for each picture position. The aspect
ratio can be changed and saved for each picture position.
• When saving the Picture Position, temporarily move the picture from the
saving point down 5 cm or more. Move the picture up again and save.
This improves the precision of the Picture Position when calling it.
• After you have selected and confirmed the lens position, the lens starts
to move. Do not touch the lens and the area around the lens, otherwise
it may cause injury or a malfunction.
• If you press any button on the unit while the lens is moving, the lens stops.
In this case, select the lens position again or adjust the lens manually.
• When you use a 2.35:1 or a 16:9 subtended screen angle with the
Picture Position function, make sure that the installation position is
suitable (page 16).
• The Picture Position function is not guaranteed to reproduce the lens
settings precisely.
Notes
