Sony VPL-VW760ES Service Manual

2-10 (E)
VPL-VW760ES
2-6. Device Adjustment Item Initialize Data
Memory Name Set Memory
Panel Driver 13 P.Drv/V Common R High 414
14 P.Drv/V Common R Low 75
15 P.Drv/V Common G High 389
16 P.Drv/V Common G Low 51
17 P.Drv/V Common B High 389
18 P.Drv/V Common B Low 51
25 P.Drv/G Panel QZ 0
26 Panel/Temp R 0
27 Panel/Temp G 0
28 Panel/Temp B Read
*1
29 Panel/Ref Temp R 464
30 Panel/Ref Temp G 460
31 Panel/Ref Temp B 475
32 Panel/Still Mode 0
Display Engine 1 DE/LUT SW 1
2 DE/UF SW 1
6 DE/R REG H Adjust
7 DE/R REG V Adjust
8 DE/B REG H Adjust
9 DE/B REG V Adjust
15 DE/WB SW 1
16 DE/PWM DELAY 600
17 DE/Flash Put 0
18 AREG/LENS H AREA 192
19 AREG/LENS V AREA 270
20 AREG/AUTOREG WAIT 3
21 AREG/SERVICE ON 1
22 AREG/ZONE RH UL Adjust
23 AREG/ZONE RH UC Adjust
24 AREG/ZONE RH UR Adjust
25 AREG/ZONE RH ML Adjust
26 AREG/ZONE RH MC Adjust
27 AREG/ZONE RH MR Adjust
28 AREG/ZONE RH DL Adjust
29 AREG/ZONE RH DC Adjust
30 AREG/ZONE RH DR Adjust
31 AREG/ZONE RV UL Adjust
32 AREG/ZONE RV UC Adjust
33 AREG/ZONE RV UR Adjust
34 AREG/ZONE RV ML Adjust
35 AREG/ZONE RV MC Adjust
36 AREG/ZONE RV MR Adjust
37 AREG/ZONE RV DL Adjust
38 AREG/ZONE RV DC Adjust
39 AREG/ZONE RV DR Adjust
40 AREG/ZONE BH UL Adjust
41 AREG/ZONE BH UC Adjust
*1: In this unit, only B is displayed.

Sony VPL-VW760ES Specifications

General

Matrix size	0.74 \
Native aspect ratio	-
Projection distance	- m
Vertical scan range	48 - 92 Hz
Horizontal scan range	19 - 72 kHz
Projection technology	SXRD
Screen size compatibility	60 - 300 \
Projector native resolution	DCI 4K (4096x2160)
Focus	Auto
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-80 - 85 %
Horizontal lens shift range	-31 - 31 %
Supported video modes	480p, 576p, 720p, 1080p, 2160p
Supported graphics resolutions	1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
Noise level	24 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR
DVI port	No
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	1
VGA (D-Sub) ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	35 - 85 %
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	430 W
Power consumption (network standby)	1 W
Light source type	Laser
Service life of light source	- h
Placement	Desktop
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema

Weight and Dimensions

Depth	496 mm
Width	560 mm
Height	223 mm
Weight	20000 g
