Sony WALKMAN WM-FS420RS User Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 23 —
C604 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C605 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C606 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C607 1-135-187-21 TANTAL. CHIP 2.2uF 20.00% 4V
C608 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C701 1-124-434-00 ELECT 220uF 20.00% 4V
C702 1-104-483-11 ELECT 470uF 20.00% 4V
C703 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C704 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C705 1-115-416-11 CERAMIC CHIP 1000PF 5.00% 25V
C706 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C707 1-115-416-11 CERAMIC CHIP 1000PF 5.00% 25V
C708 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C709 1-124-433-00 ELECT 100uF 20.00% 4V
C710 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C711 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C712 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C713 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C714 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C715 1-163-059-00 CERAMIC CHIP 0.01uF 10% 50V
C716 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C717 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C718 1-164-505-11 CERAMIC CHIP 2.2uF 16V
< FILTER >
CF1 1-781-137-11 FILTER ASSY, CERAMIC
CF2 1-781-344-21 FILTER, AM CERAMIC
< TRIMMER >
CT1 1-141-422-11 CAP, ADJ 10PF
CT2 1-141-422-11 CAP, ADJ 10PF
< DIODE >
D1 8-719-076-70 DIODE KV1520TL00
D2 8-719-053-30 DIODE MA357(E)-(TX).SO
D3 8-719-053-30 DIODE MA357(E)-(TX).SO
D301 8-719-073-01 DIODE MA111-TX
D701 8-719-049-09 DIODE 1SS367-T3SONY
D705 8-719-158-49 DIODE MA8120-TX
D706 8-719-049-09 DIODE 1SS367-T3SONY
< FERRITE BEAD >
FB101 1-414-760-21 FERRITE 0uH
FB201 1-414-760-21 FERRITE 0uH
FB301 1-414-813-11 FERRITE 0uH
< FILTER >
FL1 1-236-711-21 FILTER, BAND PASS
< IC >
IC1 8-759-493-20 IC TA2111F-(EL)
IC301 8-759-665-91 IC LB8115W-NA-TLM
IC701 8-759-664-41 IC LC72348W-9906
IC702 8-759-469-63 IC S-81215SGUP-DQK-T1
< JUMPER >
JC1 1-216-296-91 SHORT 0
JC2 1-216-296-91 SHORT 0
JC302 1-216-864-11 METAL CHIP 0 5% 1/16W
JC303 1-216-864-11 METAL CHIP 0 5% 1/16W
JC701 1-216-864-11 METAL CHIP 0 5% 1/16W
JC703 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L1 1-754-096-11 ANTENNA, FERRITE-ROD (MW)
L2 1-419-520-11 COIL (OSC)
L3 1-416-528-21 COIL, AIR-CORE
L4 1-416-449-11 COIL, AIR-CORE
L701 1-412-995-21 INDUCTOR 22uH
L702 1-412-033-11 INDUCTOR CHIP 220uH
< FLUORESCENT INDICATOR >
ND701 1-803-305-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q1 8-729-602-21 TRANSISTOR 2SC4154TP-1EF (US,CND,MX)
Q2 8-729-117-73 TRANSISTOR 2SC4178-T1F14
Q3 8-729-028-76 TRANSISTOR RN2307-TE85L
Q5 8-729-028-76 TRANSISTOR RN2307-TE85L (E,AEP)
Q6 8-729-014-12 TRANSISTOR RN1311-TE85L (E,AEP)
Q91 8-729-230-60 TRANSISTOR 2SA1586YG-TE85L
Q92 8-729-014-12 TRANSISTOR RN1311-TE85L
Q101 8-729-421-26 TRANSISTOR RN1310-TE85L
Q102 8-729-013-37 TRANSISTOR 2SC4213-AB-TE85L
Q201 8-729-421-26 TRANSISTOR RN1310-TE85L
Q202 8-729-013-37 TRANSISTOR 2SC4213-AB-TE85L
Q301 8-729-028-99 TRANSISTOR RN1307-TE85L
Q302 8-729-028-99 TRANSISTOR RN1307-TE85L
Q303 8-729-230-60 TRANSISTOR 2SA1586YG-TE85L
Q304 8-729-014-12 TRANSISTOR RN1311-TE85L
Q501 8-729-230-72 TRANSISTOR 2SA1362-YG-EL
Q502 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q503 8-729-403-17 TRANSISTOR XN1215-TX
< RESISTOR >
R1 1-216-821-11 METAL CHIP 1K 5% 1/16W
(US,CND,MX)
R2 1-216-851-11 METAL CHIP 330K 5% 1/16W
R3 1-216-851-11 METAL CHIP 330K 5% 1/16W
R4 1-216-839-11 METAL CHIP 33K 5% 1/16W
R5 1-216-837-11 METAL CHIP 22K 5% 1/16W
R6 1-216-853-11 METAL CHIP 470K 5% 1/16W
R7 1-216-853-11 METAL CHIP 470K 5% 1/16W
R8 1-216-793-11 RES-CHIP 4.7 5% 1/16W
R9 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R10 1-216-809-11 METAL CHIP 100 5% 1/16W
R11 1-216-841-11 METAL CHIP 47K 5% 1/16W
R12 1-216-793-11 RES-CHIP 4.7 5% 1/16W
R13 1-216-817-11 METAL CHIP 470 5% 1/16W
R14 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R15 1-216-837-11 METAL CHIP 22K 5% 1/16W
MAIN
