Sony WALKMAN WM-FS420RS User Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 24 —
R16 1-216-837-11 METAL CHIP 22K 5% 1/16W
R17 1-216-845-11 METAL CHIP 100K 5% 1/16W
R18 1-216-815-11 METAL CHIP 330 5% 1/16W
R19 1-216-109-00 METAL CHIP 330K 5% 1/10W
R20 1-216-109-00 METAL CHIP 330K 5% 1/10W
R21 1-216-813-11 METAL CHIP 220 5% 1/16W
R22 1-216-797-11 METAL CHIP 10 5% 1/16W
R91 1-216-821-11 METAL CHIP 1K 5% 1/16W
R103 1-216-855-11 METAL CHIP 680K 5% 1/16W
R104 1-216-835-11 METAL CHIP 15K 5% 1/16W
R105 1-216-835-11 METAL CHIP 15K 5% 1/16W
R106 1-216-819-11 METAL CHIP 680 5% 1/16W
R107 1-216-811-11 METAL CHIP 150 5% 1/16W
R108 1-216-795-11 RES-CHIP 6.8 5% 1/16W
R109 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R203 1-216-855-11 METAL CHIP 680K 5% 1/16W
R204 1-216-835-11 METAL CHIP 15K 5% 1/16W
R205 1-216-835-11 METAL CHIP 15K 5% 1/16W
R206 1-216-819-11 METAL CHIP 680 5% 1/16W
R207 1-216-811-11 METAL CHIP 150 5% 1/16W
R208 1-216-795-11 RES-CHIP 6.8 5% 1/16W
R209 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R301 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R302 1-216-234-00 RES-CHIP 33K 5% 1/8W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R304 1-216-833-91 RES-CHIP 10K 5% 1/16W
R305 1-216-246-00 RES-CHIP 100K 5% 1/8W
R306 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R307 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R308 1-216-833-11 RES-CHIP 10K 5% 1/16W
R501 1-216-833-11 RES-CHIP 10K 5% 1/16W
R502 1-216-847-11 METAL CHIP 150K 5% 1/16W
R503 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R504 1-216-819-11 METAL CHIP 680 5% 1/16W
R601 1-216-821-11 METAL CHIP 1K 5% 1/16W
R602 1-216-821-11 METAL CHIP 1K 5% 1/16W
R603 1-216-833-11 RES-CHIP 10K 5% 1/16W
R604 1-216-845-11 METAL CHIP 100K 5% 1/16W
R605 1-216-821-11 METAL CHIP 1K 5% 1/16W
R606 1-216-833-11 RES-CHIP 10K 5% 1/16W
R607 1-216-198-91 RES-CHIP 1K 5% 1/8W
R701 1-216-833-11 RES-CHIP 10K 5% 1/16W
R703 1-216-833-11 RES-CHIP 10K 5% 1/16W
R704 1-216-841-11 METAL CHIP 47K 5% 1/16W
R705 1-216-845-11 METAL CHIP 100K 5% 1/16W
(US,CND,AEP,MX)
R706 1-216-845-11 METAL CHIP 100K 5% 1/16W
(US,CND,E,MX)
R707 1-216-845-11 METAL CHIP 100K 5% 1/16W
(E)
R708 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP)
R709 1-216-833-11 RES-CHIP 10K 5% 1/16W
R710 1-216-833-11 RES-CHIP 10K 5% 1/16W
R711 1-216-833-11 RES-CHIP 10K 5% 1/16W
R712 1-216-833-11 RES-CHIP 10K 5% 1/16W
R713 1-216-833-11 RES-CHIP 10K 5% 1/16W
R714 1-216-833-11 RES-CHIP 10K 5% 1/16W
R715 1-216-833-11 RES-CHIP 10K 5% 1/16W
R716 1-216-833-11 RES-CHIP 10K 5% 1/16W
R717 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R718 1-216-845-11 METAL CHIP 100K 5% 1/16W
R719 1-216-847-11 METAL CHIP 150K 5% 1/16W
R721 1-216-845-11 METAL CHIP 100K 5% 1/16W
R723 1-216-226-00 RES-CHIP 15K 5% 1/8W
R724 1-216-845-11 METAL CHIP 100K 5% 1/16W
R725 1-216-805-11 METAL CHIP 47 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-184-11 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-241-916-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S301 1-762-742-61 SWITCH, DETECTION (SMALL TYPE)
S302 1-771-586-41 SWITCH, SLIDE (AVLS)
S303 1-762-742-61 SWITCH, DETECTION (SMALL TYPE)
S304 1-762-624-11 SWITCH, SLIDE (LOCAL/DX)
S701 1-771-586-41 SWITCH, SLIDE (HOLD)
< TRANSFORMER >
T1 1-406-694-11 COIL, AM IFT
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X1 1-781-137-11 FILTER ASSY, CERAMIC
X701 1-577-262-11 VIBRATOR, CRYSTAL 75kHz
**************************************************************
* 1-675-511-11 HEADPHONE BOARD
*****************
< JACK >
J301 1-565-376-11 JACK (PHONES)
**************************************************************
MAIN HEADPHONE

Sony WALKMAN WM-FS420RS Specifications

General

Brand	Sony
Model	WALKMAN WM-FS420RS
Category	Cassette Player
Language	English
