— 15 —
6-2. MAIN BOARD SECTION
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
54
55
56
57
58
53
52
51
51 3-703-816-73 SCREW (M1.4), SPECIAL HEAD
52 A-3021-303-A MAIN BOARD, COMPLETE (EX190:FR)
52 A-3021-304-A MAIN BOARD, COMPLETE(EX190:US,CND,AEP)
52 A-3021-305-A MAIN BOARD, COMPLETE (EX190:E)
52 A-3021-306-A MAIN BOARD, COMPLETE (EX192:AEP,E,EA)
52 A-3021-307-A MAIN BOARD, COMPLETE (EX192:FR)
53 3-040-912-01 TERMINAL (+), BATTERY
54 3-019-944-01 BUTTON (STOP)
55 3-019-943-01 BUTTON (REW)
56 3-019-941-01 BUTTON (PLAY)
57 3-019-942-01 BUTTON (FF)
58 3-040-913-01 TERMINAL (-), BATTERY
To Next Page
