Sony WM-EX190 - Transistors; Variable Resistors; Switches; Thermistors

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 19 —
MAIN
JR32 1-216-296-91 SHORT 0
JR33 1-216-296-91 SHORT 0
JR34 1-216-296-91 SHORT 0
JR35 1-216-296-91 SHORT 0
JR36 1-216-296-91 SHORT 0
JR37 1-216-864-11 METAL CHIP 0 5% 1/16W
JR38 1-216-296-91 SHORT 0
< TRANSISTOR >
Q301 8-729-900-52 TRANSISTOR DTC114YK
< RESISTOR >
R103 1-216-839-11 RES-CHIP 33K 5% 1/16W
R104 1-216-817-11 RES-CHIP 470 5% 1/16W
(EXECEPT EX192:FR)
R104 1-216-819-11 RES-CHIP 680 5% 1/16W
(EX192:FR)
R105 1-216-855-11 RES-CHIP 680K 5% 1/16W
R106 1-216-809-11 RES-CHIP 100 5% 1/16W
(EXECEPT EX192:FR)
R106 1-216-811-11 RES-CHIP 150 5% 1/16W
(EX192:FR)
R107 1-216-170-00 RES-CHIP 68 5% 1/8W
(EX190:FR)
R107 1-216-150-91 RES-CHIP 10 5% 1/8W
(EX190:US,CND,AEP)
R107 1-216-154-91 RES-CHIP 15 5% 1/8W
(EX190:E/EX192:AEP,E,EA)
R107 1-216-174-00 RES-CHIP 100 5% 1/8W
(EX192:FR)
R108 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R109 1-216-154-91 RES-CHIP 15 5% 1/8W
(EX190:FR)
R109 1-216-296-91 SHORT (EXECEPT EX190:FR)
R110 1-216-813-11 RES-CHIP 220 5% 1/16W
(EX190:E/EX192:AEP,E,EA)
R110 1-216-821-11 RES-CHIP 1K 5% 1/16W
(EX192:FR)
R110 1-216-817-11 RES-CHIP 470 5% 1/16W
(EX190:US,CND,AEP,FR)
R150 1-216-823-11 RES-CHIP 1.5K 5% 1/16W
R203 1-216-839-11 RES-CHIP 33K 5% 1/16W
R204 1-216-817-11 RES-CHIP 470 5% 1/16W
(EXECEPT EX192:FR)
R204 1-216-819-11 RES-CHIP 680 5% 1/16W
(EX192:FR)
R205 1-216-855-11 METAL CHIP 680K 5% 1/16W
R206 1-216-809-11 RES-CHIP 100 5% 1/16W
(EXECEPT EX192:FR)
R206 1-216-811-11 RES-CHIP 150 5% 1/16W
(EX192:FR)
R207 1-216-170-00 RES-CHIP 68 5% 1/8W
(EX190:FR)
R207 1-216-150-91 RES-CHIP 10 5% 1/8W
(EX190:US,CND,AEP)
R207 1-216-154-91 RES-CHIP 15 5% 1/8W
(EX190:E/EX192:AEP,E,EA)
R207 1-216-174-00 RES-CHIP 100 5% 1/8W
(EX192:FR)
R208 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R209 1-216-154-91 RES-CHIP 15 5% 1/8W
(EX190:FR)
R209 1-216-296-91 SHORT (EXECEPT EX190:FR)
R210 1-216-813-11 RES-CHIP 220 5% 1/16W
(EX190:E/EX192:AEP,E,EA)
R210 1-216-821-11 RES-CHIP 1K 5% 1/16W
(EX192:FR)
R210 1-216-817-11 RES-CHIP 470 5% 1/16W
(EX190:US,CND,AEP,FR)
R324 1-216-839-91 RES-CHIP 33K 5% 1/16W
R325 1-216-861-91 RES-CHIP 2.2M 5% 1/16W
(EX192)
R327 1-216-789-11 RES-CHIP 2.2 5% 1/16W
R601 1-216-198-91 RES-CHIP 1K 5% 1/8W
R605 1-216-833-91 RES-CHIP 10K 5% 1/16W
R606 1-216-845-11 RES-CHIP 100K 5% 1/16W
R608 1-216-833-91 RES-CHIP 10K 5% 1/16W
R609 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R610 1-216-821-11 RES-CHIP 1K 5% 1/16W
R611 1-216-817-11 RES-CHIP 470 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-544-21 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-238-663-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S301 1-762-302-11 SWITCH, DETECTION (SMALL TYPE)(TAPE
POWER)
S303 1-771-824-11 SWITCH, SLIDE (MEGA BASS)
S305 1-692-298-11 SWITCH, SLIDE (AVLS)
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE
************************************************************
MISCELLANEOUS
**************
M901 1-763-073-11 MOTOR (REEL/CAPSTAN)(WITH PULLY)
HP901 1-500-640-11 HEAD, MAGNETIC (PLAYBACK)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-505-521-11 HEADPHONE (MDR-023)
(EX190:US,CND,AEP,FR)
3-022-755-01 CLIP, BELT
3-868-007-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH,PORTUGUESE,GERMAN,
ITALIAN,DUTCH,SWEDISH,FINNISH,RUSSIAN,
HUNGARIAN,CZECH,POLISH,GREEK,SLOVAK)
(EX190:AEP/EX192:AEP)
3-868-007-21 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,CHINESE,ARABIC)
(EX190:US,CND,E,FR/EX192:EA,FR)
3-868-007-31 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,CHINESE,ARABIC)
(EX190:EEX192:E)
8-953-130-90 HEADPHONE MDR-E805LP (EX190:E/EX192)
