– 7 –
3-3.
ORNAMENT (OPEN) BLOCK ASSY
3-4. SUB BOARD, LEAF SWITCH, MAIN BOARD
1
ornament (open) block ass
y
mechanism deck block
3
screw (M1.4x1.4)
5
screw (M1.4)
6
SUB board
2
screw (M1.4)
!£
MAIN board
1
screw
4
Unsolder the 6 places.
!¡
Unsolder the motor.
9
Unsolder the
plunger.
0
Unsolder the
flexible board.
!™
claw
7
screw (M1.4)
8
leaf switch
8
10
