Adjustment Location :
L1 : AM Tracking Adjustment
CT1 : AM Tracking Adjustment
L2 : FM Tracking Adjustment
T2 : AM Frequency Coverage Adjustment
L3 : FM Frequency Coverage Adjustmen
T1 : AM IF Alignment
[MAIN BOARD] (Conductor Side)
Connection Point :
[MAIN BOARD] (Component side)
To Next Page
