WM-FX481
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C602 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C603 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C604 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C605 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C606 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C607 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C701 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C704 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C705 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C706 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C710 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C711 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C712 1-126-916-11 ELECT 1000uF 20% 6.3V
C714 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C721 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
<TRIMMER>
CT1 1-141-422-11 CAP, ADJ 10PF (AM TRACKING)
<DIODE>
D1 8-719-072-60 DIODE SVC347T-TL
D2 8-719-050-97 DIODE MA357(E)-(TX).SO
D4 8-719-050-97 DIODE MA357(E)-(TX).SO
D5 8-719-038-20 DIODE 1SS314 (5E,6E)
D404 8-719-404-50 DIODE MA111-TX
D703 8-719-049-09 DIODE 1SS367-T3SONY
D704 8-719-420-87 DIODE MA8130
<FERRITE BEAD>
FB101 1-500-245-11 FERRITE 0UH
FB201 1-500-245-11 FERRITE 0UH
FB301 1-500-245-11 FERRITE 0UH
FB302 1-216-864-11 METAL CHIP 0 5% 1/16W
<IC>
IC1 8-752-073-35 IC CXA1960Q
IC301 8-759-665-91 IC LB8115W-NA-TLM
IC701 8-759-457-70 IC XC62RP1602MR
IC702 8-759-829-36 IC LC72348W-CFX1721 (5E,6E)
IC702 8-759-829-35 IC LC72348W-CFX1726 (9E,CH)
<JACK>
J301 1-565-287-11 JACK ( i )
<JUMPER RESISTOR>
JC1 1-216-821-11 METAL CHIP 1K 5% 1/16W
(9E,CH)
JR3 1-216-864-11 METAL CHIP 0 5% 1/16W
(9E,CH)
JC5 1-216-864-11 METAL CHIP 0 5% 1/16W
(5E,6E)
<COIL>
L1 1-412-967-31 INDUCTOR 0.1uH
L2 1-412-967-31 INDUCTOR 0.1uH
L3 1-754-124-21 ANTENNA, FERRITE-ROD (AM TRACKIG)
L4 1-424-763-11 COIL, RF (FM) (FM TRACKING)
L6 1-469-781-21 INDUCTOR 30nH
L7 1-419-540-11 COIL, OSCILLATION (AM)
(AM FREQUENCY COVERAGE)
L402 1-412-033-11 INDUCTOR CHIP 220uH
L702 1-412-995-21 INDUCTOR 22uH
<TRANSISTOR>
Q3 8-729-423-52 TRANSISTOR 2SC3931-C
Q4 8-729-602-21 TRANSISTOR 2SC4154-F (5E,6E)
Q200 8-729-402-13 TRANSISTOR XN1501
Q301 8-729-422-54 TRANSISTOR XN4215
Q501 8-729-046-90 TRANSISTOR 2SB970-(TX).S0
Q502 8-729-402-13 TRANSISTOR XN1501
Q701 8-729-046-90 TRANSISTOR 2SB970-(TX).S0
<RESISTOR>
R2 1-216-821-11 METAL CHIP 1K 5% 1/16W
(5E,6E)
R3 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R4 1-216-817-11 METAL CHIP 470 5% 1/16W
R5 1-216-833-11 METAL CHIP 10K 5% 1/16W
R6 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R7 1-216-833-11 METAL CHIP 10K 5% 1/16W
R8 1-216-833-11 METAL CHIP 10K 5% 1/16W
R9 1-216-864-11 METAL CHIP 0 5% 1/16W
R10 1-216-833-11 METAL CHIP 10K 5% 1/16W
R11 1-216-833-11 METAL CHIP 10K 5% 1/16W
R12 1-216-803-11 METAL CHIP 33 5% 1/16W
R13 1-216-813-11 METAL CHIP 220 5% 1/16W
R14 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R15 1-216-845-11 METAL CHIP 100K 5% 1/16W
R17 1-216-833-11 METAL CHIP 10K 5% 1/16W
R18 1-216-845-11 METAL CHIP 100K 5% 1/16W
R20 1-216-821-11 METAL CHIP 1K 5% 1/16W
R21 1-216-821-11 METAL CHIP 1K 5% 1/16W
(5E,6E)
R22 1-216-833-11 METAL CHIP 10K 5% 1/16W
R40 1-216-821-11 METAL CHIP 1K 5% 1/16W
(5E,6E)
R101 1-216-835-11 METAL CHIP 15K 5% 1/16W
R102 1-216-835-11 METAL CHIP 15K 5% 1/16W
R103 1-216-855-11 METAL CHIP 680K 5% 1/16W
R104 1-216-819-11 METAL CHIP 680 5% 1/16W
R105 1-216-815-11 METAL CHIP 330 5% 1/16W
R106 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R107 1-216-864-11 METAL CHIP 0 5% 1/16W
R108 1-216-833-11 METAL CHIP 10K 5% 1/16W
R200 1-216-821-11 METAL CHIP 1K 5% 1/16W
R201 1-216-835-11 METAL CHIP 15K 5% 1/16W
R202 1-216-835-11 METAL CHIP 15K 5% 1/16W
R203 1-216-855-11 METAL CHIP 680K 5% 1/16W
R204 1-216-819-11 METAL CHIP 680 5% 1/16W
