3
WM-FX481
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. CABINET (FRONT), CABINET (CENTER) SUB ASSY
2-2. MAIN BOARD
z
The equipment can be removed using the following procedure.
Main boardCabinet (center) sub ASSY
Cassette holder
Mechanism deck Belt, Capstan/reel motor (M601)
Magnetic head (playback) (HP601)
Set
Cabinet (front)
Note : Use the precision driver with coverd a point
by cloth to release the claw.
Be careful not to damage claws.
Cabinet (Front)
Cabinet (center) sub ASS
Cassette holder
4 Claw
4 Claw
2
5
1 Claws
1 Claws
3 Claws
1 Claws
Main board
1 Screw
Orange
Black
White
Red
Cabinet (center) sub ASS
Head flexible board
2 Remove solder
3 Claws
4
