5
WM-FX481
1 Insert the spring (torsion) to the L shape slot as shown in the figure.
2,3 Insert the hinge of the “Cassette holder ”.
4 Close the “Cassette holder” then press it.
2-5. CASSETTE HOLDER
z
CAUTIONS DURING ASSEMBLY
Cassette holder
4 Spring (torsion)
1
5
Hinge
Cabinet (center)
sub ASSY
Hinge
Projection
Projection
Hinge
Hinge
Projection
Projection
3 Move the hinge away
from projection
2 Move the hinge away
from projection
L shape slot
Spring (torsion)
Hinge
Hinge
Cassette holde
Cabinet (center) sub ASSY
1
2
4
3
