– 35 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C206 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-113-619-11 CERAMIC CHIP 0.47uF 10% 6.3V
C208 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C210 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C211 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C301 1-119-663-11 TANTAL. CHIP 47uF 20% 2.5V
C302 1-107-815-11 TANTAL. CHIP 2.2uF 20% 4V
C303 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C304 1-125-984-21 TANTAL. CHIP 22uF 20% 4V
C305 1-125-984-21 TANTAL. CHIP 22uF 20% 4V
C306 1-113-619-11 CERAMIC CHIP 0.47uF 10% 6.3V
C307 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C308 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C309 1-135-149-21 TANTAL. CHIP 2.2uF 20% 10V
C310 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C311 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C312 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C313 1-115-156-11 CERAMIC CHIP 1uF 10V
C314 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C315 1-115-156-11 CERAMIC CHIP 1uF 10V
C316 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C318 1-135-201-11 TANTAL. CHIP 10uF 20% 4V
C319 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C320 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C321 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C325 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C601 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C604 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C606 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-135-177-21 TANTAL. CHIP 1uF 20% 20V
C804 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C805 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C806 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C807 1-125-984-21 TANTAL. CHIP 22uF 20% 4V
C808 1-115-156-11 CERAMIC CHIP 1uF 10V
C809 1-127-808-91 TANTAL. CHIP 10uF 20% 6.3V
C810 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C811 1-115-156-11 CERAMIC CHIP 1uF 10V
C812 1-125-984-21 TANTAL. CHIP 22uF 20% 4V
C813 1-115-156-11 CERAMIC CHIP 1uF 10V
CB301 1-127-678-21 CERAMIC CHIP 330PF 0 50V
< FILTER >
CF1 1-767-362-11 FILTER, CERAMIC (10.7MHz)
CF2 1-767-480-11 FILTER, CERAMIC (AM) (450kHz)
< DIODE >
D1 8-719-053-30 DIODE MA357 (E)-(TX).SO
D2 8-719-053-30 DIODE MA357 (E)-(TX).SO
D3 8-719-072-58 DIODE SVC347-TL
D4 8-719-404-50 DIODE MA111-TX
D5 8-719-049-09 DIODE 1SS367-T3SONY
D6 8-719-422-37 DIODE MA8051-TX
D101 8-719-422-37 DIODE MA8051-TX
D201 8-719-422-37 DIODE MA8051-TX
D301 8-719-422-37 DIODE MA8051-TX
D302 8-719-422-37 DIODE MA8051-TX
D303 8-719-422-37 DIODE MA8051-TX
D304 8-719-422-37 DIODE MA8051-TX
D305 8-719-422-37 DIODE MA8051-TX
D801 8-719-049-09 DIODE 1SS367-T3SONY
D802 8-719-420-87 DIODE MA8130-TX
D803 8-719-404-50 DIODE MA111-TX
D804 8-719-420-51 DIODE MA729-TX
< FUSE >
F1 1-533-792-11 FUSE (SMD) 0.25A/125V
< FERRITE BEAD >
FB1 1-500-445-21 FERRITE 0uH
FB2 1-500-445-21 FERRITE 0uH
FB3 1-500-445-21 FERRITE 0uH
FB4 1-500-245-11 FERRITE 0uH
FB5 1-500-245-11 FERRITE 0uH
FB6 1-500-245-11 FERRITE 0uH
FB7 1-500-245-11 FERRITE 0uH
< IC >
IC1 8-759-362-23 IC TA7371AF-EL
IC2 8-759-362-25 IC TA2022AFN-EL
IC3 8-759-594-67 IC TC9327AF-606
IC4 8-759-457-68 IC AK93C45AV-L
IC5 8-759-387-31 IC TC75S55F (TE85R)
IC6 8-759-457-70 IC XC62RP1602MR
IC301 8-759-579-12 IC TA2123AF (EL)
IC302 8-759-488-80 IC NJM2185AV-TE2
IC601 8-759-356-46 IC MM1279XVBE
IC801 8-759-553-28 IC XC6383C251ML
< JACK >
J701 1-779-867-81 JACK (2 REMOTE)
< SHORT >
JC101 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT FX673: FR)
JC201 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT FX673: FR)
< COIL >
L1 1-469-373-21 INDUCTOR CHIP 95nH
L2 1-416-941-21 COIL (FM OSC)
L3 1-410-997-42 INDUCTOR CHIP 2.2uH
L4 1-412-995-21 INDUCTOR CHIP 22uH
L5 1-754-046-11 ANTENNA, FERRITE-ROD (AM)
L6 1-412-995-21 INDUCTOR CHIP 22uH
L7 1-412-967-31 INDUCTOR CHIP 0.1uH
L8 1-412-967-31 INDUCTOR CHIP 0.1uH
L801 1-412-034-11 INDUCTOR CHIP 330uH
L802 1-412-995-21 INDUCTOR CHIP 22uH
MAIN
