CASE BLOCK ASSY
Note: Follow the disassembly procedure in the numerical order given.
SECTION 3
DISASSEMBLY
This set can be disassembled in the order shown below.
Set Case Block Assy Main Board
Holder (F) Assy
Pinch Lever
(N)/(R) Assy
Head, Magnetic (HP901
)
Belt (F2) Motor (Capstan/Reel) (M601)
Ornament
Block Assy,
Reel
Lid Block
Assy,
Cassette
1 Open the lid battery case. 
3 lid, battery case
2 claw
4 screw
(M1.4 × 2.5)
4 two screws
(M1.4 × 2.5)
5 Remove the case block ass
y
in the direction of the arrow.
4 two screws
(M1.4 × 2.5)
