– 8 –
MAIN BO
ARD
BEL
T (F2)
1
flexib
le board
5
screw
(M1.4)
6
MAIN board
3
Remov
e two solders
of plunger solenoid.
2
Remov
e four solders
of leaf switch.
S1
5
two screws
4
Remov
e four solders
of motor
.
slider
Note:
On installation MAIN boar
d
adjust the S1 and slider
.
3
belt
2
terminal board (T3)
1
Remov
e the solder
of terminal board.
7
9
