– 37 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R73 1-218-831-11 RES,CHIP 220 0.5% 1/16W
R74 1-218-875-11 RES,CHIP 15K 0.5% 1/16W
R75 1-218-839-11 RES,CHIP 470 0.5% 1/16W
R76 1-218-875-11 RES,CHIP 15K 0.5% 1/16W
R77 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R101 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R102 1-216-837-11 METAL CHIP 22K 5% 1/16W
R103 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R104 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R105 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R106 1-216-811-11 METAL CHIP 150 5% 1/16W
(EXCEPT FX673: FR)
R106 1-216-821-11 METAL CHIP 1K 5% 1/16W
(FX673: FR)
R107 1-216-837-11 METAL CHIP 22K 5% 1/16W
R108 1-216-811-11 METAL CHIP 150 5% 1/16W
R109 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R110 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R111 1-216-849-11 METAL CHIP 220K 5% 1/16W
R112 1-216-807-11 METAL CHIP 68 5% 1/16W
(FX673: FR)
R201 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R202 1-216-837-11 METAL CHIP 22K 5% 1/16W
R203 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R204 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R205 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R206 1-216-811-11 METAL CHIP 150 5% 1/16W
(EXCEPT FX673: FR)
R206 1-216-821-11 METAL CHIP 1K 5% 1/16W
(FX673: FR)
R207 1-216-837-11 METAL CHIP 22K 5% 1/16W
R208 1-216-811-11 METAL CHIP 150 5% 1/16W
R209 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R210 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R211 1-216-849-11 METAL CHIP 220K 5% 1/16W
R212 1-216-807-11 METAL CHIP 68 5% 1/16W
(FX673: FR)
R301 1-216-849-11 METAL CHIP 220K 5% 1/16W
R302 1-216-833-11 RES,CHIP 10K 5% 1/16W
R303 1-216-835-11 METAL CHIP 15K 5% 1/16W
R304 1-216-837-11 METAL CHIP 22K 5% 1/16W
R305 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R306 1-216-851-11 METAL CHIP 330K 5% 1/16W
R307 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R308 1-218-887-11 RES,CHIP 47K 0.5% 1/16W
R309 1-216-841-11 METAL CHIP 47K 5% 1/16W
R310 1-216-845-11 METAL CHIP 100K 5% 1/16W
R311 1-216-841-11 METAL CHIP 47K 5% 1/16W
R312 1-216-845-11 METAL CHIP 100K 5% 1/16W
R313 1-218-899-11 RES,CHIP 150K 0.5% 1/16W
R601 1-216-837-11 METAL CHIP 22K 5% 1/16W
R602 1-216-809-11 METAL CHIP 100 5% 1/16W
R603 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R604 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R605 1-216-833-11 RES,CHIP 10K 5% 1/16W
R607 1-216-845-11 METAL CHIP 100K 5% 1/16W
R801 1-216-849-11 METAL CHIP 220K 5% 1/16W
R802 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R803 1-216-817-11 METAL CHIP 470 5% 1/16W
R804 1-216-805-11 METAL CHIP 47 5% 1/16W
R805 1-216-819-11 METAL CHIP 680 5% 1/16W
R806 1-216-819-11 METAL CHIP 680 5% 1/16W
R807 1-216-845-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB1 1-233-811-21 RES, NETWORK 470K (3216)
RB601 1-233-873-21 RES, NETWORK 220K (CHIP TYPE) (3216)
< VARIABLE RESISTOR >
RV1 1-223-587-11 RES, ADJ, CARBON 22K
RV301 1-225-684-21 RES, VAR, CARBON 30K/30K (VOL)
RV601 1-223-584-11 RES, ADJ, CARBON 2.2K
< SWITCH >
S1 1-771-475-21 SWITCH, SLIDE (DIRECTION)
S2 1-572-922-11 SWITCH, SLIDE (HOLD)
S3 1-771-053-21 SWITCH, KEY BOARD (p RADIO OFF)
S4 1-771-053-21 SWITCH, KEY BOARD
(TUNE/PRESET +, FF AMS)
S5 1-771-053-21 SWITCH, KEY BOARD
(TUNE/PRESET -, REW AMS)
S6 1-771-053-21 SWITCH, KEY BOARD (MENU)
S7 1-771-053-21 SWITCH, KEY BOARD (SET)
S8 1-771-053-21 SWITCH, KEY BOARD (BAND, RADIO ON)
S9 1-771-053-21 SWITCH, KEY BOARD (œ REPEAT)
S10 1-771-053-21 SWITCH, KEY BOARD
(ENTER, COUNTER RESET)
< TRANSFORMER >
T1 1-416-943-21 COIL (AM OSC)
T2 1-416-942-21 COIL (AM IF)
T801 1-423-745-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR >
THP601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X1 1-767-357-11 FILTER, CERAMIC (10.7MHz)
X2 1-579-615-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
MISCELLANEOUS
**************
HP901 1-500-576-11 HEAD, MAGNETIC (PLAYBACK)
M601 1-763-166-12 MOTOR (CAPSTAN/REEL)
PM901 1-454-674-32 SOLENOID, PLUNGER
S901 1-762-553-11 SWITCH, LEAF (TAPE DETECT, ATS)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-418-019-11 REMOTE CONTROL UNIT (FX673)
1-418-409-11 REMOTE CONTROL UNIT
(RM-WMF21) (FX877)
! 1-528-252-21 BATTERY CHARGER (BC-7S)
(FX673: UK, E, HK)
1-528-299-41 BATTERY, NI-CD (NC-6WM) (FX673: CND)
! 1-528-434-13 BATTERY CHARGER (BC-7SG) (FX673: AUS)
MAIN
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
