— 6 —
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. BRACKET ASSEMBLY AND CASSETTE HOLDER ASSEMBLY
3-2. AUDIO BOARD
1
Screw (M1.4)
2
Bracket assembly
3
Screw
(M1.4)
4
Lever (B), Lock
5
Screw (M1.4)
6
Cassette holder assembly
1
Remove the solder of the
battery terminal.
3
Remove the solder of
the battery terminal.
2
Remove the solder
of the motor.
4
Remove the solder of
the switch (S901).
5
Remove the solder
of the flexible board.
6
Remove the solder of
the plunger solenoid.
7
Flexible board
(Head)
8
Screw (M1.4x2.0)
9
Screw (M1.4)
S701
Lever (NR SW)
0
Remove the Audio board
direction of arrow.
Note: Confirm if the switch lever
installs itself in the groove of
a lever (NR SW) for
assembling.
