Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
22
WM-GX221
C263 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C264 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C265 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-115-156-11 CERAMIC CHIP 1uF 10V
C303 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C304 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C305 1-115-156-11 CERAMIC CHIP 1uF 10V
C306 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C307 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C308 1-115-156-11 CERAMIC CHIP 1uF 10V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-104-852-11 TANTAL. CHIP 22uF 20.00% 10V
C311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C313 1-104-852-11 TANTAL. CHIP 22uF 20.00% 10V
C314 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C315 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C401 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C402 1-104-852-11 TANTAL. CHIP 22uF 20.00% 10V
C403 1-124-434-00 ELECT 220uF 20.00% 4V
C404 1-124-434-00 ELECT 220uF 20.00% 4V
C453 1-115-156-11 CERAMIC CHIP 1uF 10V
C454 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C456 1-115-156-11 CERAMIC CHIP 1uF 10V
C502 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C503 1-137-934-11 TANTAL. CHIP 47uF 20% 10V
C504 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C506 1-115-156-11 CERAMIC CHIP 1uF 10V
C507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C508 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C509 1-137-934-11 TANTAL. CHIP 47uF 20% 10V
C510 1-115-156-11 CERAMIC CHIP 1uF 10V
C511 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C512 1-115-156-11 CERAMIC CHIP 1uF 10V
C513 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C514 1-115-156-11 CERAMIC CHIP 1uF 10V
C515 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C516 1-115-156-11 CERAMIC CHIP 1uF 10V
C517 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C518 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C519 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C520 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C521 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C522 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C523 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C551 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C552 1-164-315-11 CERAMIC CHIP 470PF 10% 50V
C553 1-164-230-11 CERAMIC CHIP 220PF 10% 50V
C554 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C555 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C556 1-137-934-11 TANTAL. CHIP 47uF 20% 10V
C557 1-164-227-11 CERAMIC CHIP 0.022 10% 25V
C558 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C601 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C602 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C603 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C604 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C605 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C606 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C607 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C701 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C703 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C704 1-104-851-11 TANTAL. CHIP 10uF 20.00% 10V
< FILTER >
CF1 1-578-677-11 FILTER, CRYSTAL
CF2 1-795-533-71 FILTER ASSY, CERAMIC
< CONNECTOR >
CN701 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
< FILTER >
CP1 1-239-015-21 FILTER, BAND PASS
< TRIMMER >
CT1
CV1
1-141-659-11 CAP, VAR (TUNING)
< DIODE >
D1 8-719-049-09 DIODE 1SS367-T3SONY
D701 8-719-941-86 DIODE DAN202UT106
< FERRITE BEAD >
FB1 1-216-864-11 METAL CHIP 0 5% 1/16W
FB2 1-414-760-21 FERRITE 0uH
FB101 1-500-329-11 FERRITE 0uH
FB201 1-500-329-11 FERRITE 0uH
FB301 1-500-329-11 FERRITE 0uH
< IC >
IC1 6-701-564-01 IC TA2111FN(EL)
IC151 8-759-597-59 IC LM4863MTX
IC301 8-759-665-91 IC LB8115W-NA-TLM
IC501 8-759-062-63 IC TA8155FN(ER)
< JACK >
J301 1-816-213-11 JACK (i )
J401 1-794-615-11 JACK,DC(POLARITY UNIFIED TYPE) (DC IN 3V)
J501 1-766-847-51 JACK (MIC (PLUG IN POWER))
< JUMPER RESISTOR >
JR1 1-216-864-11 METAL CHIP 0 5% 1/16W
(US, CND, 5E)
JR3 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US, CND, 5E)
JR101 1-216-864-11 METAL CHIP 0 5% 1/16W
JR102 1-216-864-11 METAL CHIP 0 5% 1/16W
JR501 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L1 1-428-869-11 COIL, FERRITE-ROD ANTENNA (MW)
L2 1-428-871-21 COIL (FM RF) (EA)
L2 1-428-870-21 COIL (FM RF) (EXCEPT EA)
L3 1-428-873-21 COIL (FM OSC) (EA)
L3 1-428-872-21 COIL (FM OSC) (EXCEPT EA)
L4 1-428-875-21 COIL (AM OSC) (EA)
L4 1-428-874-21 COIL (AM OSC) (EXCEPT EA)
MAIN



Ver 1.2
