22
XP-EV600/EV600B/EV600D
Pin No.
72
73
74
75
76
77
78
79
80
I/O
I
O
O
O
I
O
O
O
O
Description
FG pulse signal input from BH6580KV-F(IC201)
Not used
Power supply control output of TA2120FN(IC701) (“H”:ON)
Latch signal output to BH6580KV-F(IC201)
Not used
Optical-pick up voltage control output (“H”:gain up)
RF AMP gain control output (“H”:gain up)
Reset signal output to BH6580KV-F(IC201) and CXD3048R(IC402)
Not used
Pin Name
FG_I
PGMSEL_O
PWRSW_O
XPOWLT_O
CHGGND_SL_I
XOPSTBY_O
OPGSW_O
XRESET_O
C2POEN_O
