Sony XVS-9000-C - Page 56

Status
dis-
play
LED1
Status
dis-
play
LED0
Status Possible cause Recovery means
0. 4 Waiting for con-
nection to
PWS-110SC1
The Group ID and Unit ID are
not set correctly.
Set the Group ID of PWS-110SC1 (Refer to “1-17.
Panel Configuration” in the ICP-X7000 Installation
Manual.)
Set the group ID and unit ID on the menu panel
(MKS-X7011). (Refer to the User’s Guide of the sys-
tem.)
Set the CA-92 board switch S1101 of this unit. (Refer
to “1-8. Description of On-board Switches and
LEDs” in the Installation Manual.)
Abnormal software status of
PWS-110SC1
Restart PWS-110SC1.
Reinstall the software package
*1
.
0 b Version mismatch Incorrect version combination
Reinstall the software package
*1
.
0 c Waiting for FPGA
initialization
Failure in initialization during
the startup process
Restart the unit or reset the switcher by Menu7315
according to the User’s Guide of the system.
MIX-57 Board (XKS-8210)
Status
dis-
play
LED1
Status
dis-
play
LED0
Status Possible cause Recovery means
0 5 Waiting for DHCP
acquisition
The network is not operating
correctly.
Re-check the network connection and settings.
PWS-110SC1 is not running. Start the PWS-110SC1.
0 9 Waiting for con-
nection to
PWS-110SC1
The Group ID and Unit ID are
not set correctly.
Set the Group ID of PWS-110SC1 (Refer to “1-17.
Panel Configuration” in the ICP-X7000 Installation
Manual.)
Set the group ID and unit ID on the menu panel
(MKS-X7011). (Refer to the User’s Guide of the sys-
tem.)
Set the CA-92 board switch S1101 of this unit. (Refer
to “1-8. Description of On-board Switches and
LEDs” in the Installation Manual.)
Abnormal software status of
PWS-110SC1
Restart PWS-110SC1.
Reinstall the software package
*1
.
0 a Mismatch of the
board ID
An unavailable board is
mounted.
Mount the correct board. (Example: XKS-7210→
XKS-8210)
0 b Version mismatch Incorrect version combination
Reinstall the software package
*1
.
0 c Waiting for FPGA
initialization
Failure in initialization during
the startup process
Restart the unit or reset the switcher by Menu7315
according to the User’s Guide of the system.
DVP-53A Board (XKS-8470)
Status
dis-
play
LED1
Status
dis-
play
LED0
Status Possible cause Recovery means
0 5 Waiting for DHCP
acquisition
The network is not operating
correctly.
Re-check the network connection and settings.
PWS-110SC1 is not running. Start the PWS-110SC1.
Continued
*1: If this manual is required, please contact your local Sony Sales Office/Service Center.
XVS-9000-C/XVS-8000-C/XVS-7000-C/XVS-6000-C
3-2
